V
•
I Chip BCM
HV Bus Converter Family
TM
TM
6,73
0.265
–In
+In
™
VICOR CORP.
MADE IN USA
PC RSV TM
•
Efficiency: 95% Typical
•
Input: HV 270 / 350 / 380 V
•
Power Density: >1000 W/in
Product Description
3
•
Current sharing: 5%
•
Isolation: 4,242 Vdc
•
Footprint: 1.1 in
2
BCM
–Out
™
VIB0003TFJ
AP4141PRS724558
S
22,0
0.87
RoHS
C
NRTL
US
U.S. PATS. LISTED ON PACKING MATERIALS & DATASHEETS
+Out
–Out
+Out
32,5
1.28
Actual size
mm
in
The HV Bus Converter Module family consists of six models that provide an isolated intermediate bus voltage to power non-isolated
POL converters. The HV BCMs offer direct conversion from PFC bus voltage to 12 V POL at up to 300 W with isolation to 4,242
Vdc. The HV family provides superior performance, the highest efficiency and power density in the smallest package available.
Model
Number*
B352F110T24
B384F120T30
VIB0001TFJ
VIB0002TFJ
VIB0003TFJ
VMB0004MFJ
Input
Voltage
(V)
330 – 365
360 – 400
330 – 365
360 – 400
330 – 365
240 – 330
Output
Voltage
(V)
10.3 – 11.4
11.25 – 12.5
10.3 – 11.4
45.0 – 50.0
41.25 – 45.62
30.0 – 41.25
Output
Power
(W)
240
300
300
300
325
240
Output
Current
(A)
24.0
25.0
28.0
7.0
7.7
7.3
Temp.
Grade
T
T
T
T
T
MIL COTS
Package
Full
Full
Full
Full
Full
Full
* Products are also available in through-hole model. See individual datasheets.
Typical Applications
™
VICOR CORP.
MADE IN USA
U.S. PATS. LISTED ON PACKING MATERIALS & DATASHEETS
+In
C
NRTL
S
US
+Out
BCM
–In
–Out
+Out
™
HV
PC RSV TM
12 V
–Out
RoHS
POL
LOAD
LOAD
™
VICOR CORP.
MADE IN USA
CD NC OS SG SC VH
PR NC IL TM PC VC
™
VICOR CORP.
MADE IN USA
U.S. PATS. LISTED ON PACKING MATERIALS & DATASHEETS
™
VICOR CORP.
MADE IN USA
+Out
U.S. PATS. LISTED ON PACKING MATERIALS & DATASHEETS
U.S. PATS. LISTED ON PACKING MATERIALS & DATASHEETS
+In
+In
NRTL
NRTL
S
S
+Out
™
BCM
PRM
VTM
–In
–Out
–Out
–In
™
vicorpower.com
800-735-6200
Rev. 1.3
–Out
–In
+Out
HV
PC RSV TM
™
+Out
PC VC TM
48 V
C
–Out
C
NRTL
C
S
US
+Out
US
US
0.8 – 55 V
RoHS
RoHS
–Out
RoHS
LOAD
+In
9/2009
Page 1 of 2
General Specifications
Parameter
MTBF
MIL-HDBK-217F
Isolation
Voltage
Capacitance
Resistance
Regulatory compliance
Thermal
Over temperature shutdown
Case-to-ambient thermal impedance
Operating junction temperature
Operating junction temperature
Storage temperature
Typ
Unit
Note
3.5
4,242
500–660
10
cTÜVus
CE Mark
RoHS
125
3.7
-40 to 125
-55 to 125
-40 to 125
Mhrs
Vdc
pF
MΩ
25°C, GB
Input to output (basic insulation)
Input to output
Input to output
UL /CSA 60950, EN60950
Low voltage directive
°C
°C / W
°C
°C
°C
minimum, junction temperature
with 0.25” heat sink @ 300 LFM
T–Grade
MIL–COTS
BCM Mechanical Outline Drawing*
Heat Sink Push-Pin Hole Pattern
2.95±0.07
ø
(2) PL
[0.116±0.003]
NON-PLATED
THROUGH HOLE
SEE NOTE 1.
(36.50)
1.437
(18.25)
0.719
DOTTED LINE
INDICATES VIC
POSITION
SEE NOTE
3
(4.37)
0.172
(11.37)
0.448
(7.00)
0.276
BOTTOM VIEW
(2.510)
0.099
(31.48)
1.240
(39.50)
1.555
SEE NOTE 2.
HEAT SINK PUSH-PIN HOLE PATTERN
( TOP SIDE SHOWN )
SEE NOTE
3
RECOMMENDED LAND PATTERN
( COMPONENT SIDE SH OWN )
NOTES:
1. MAINTAIN
3.5/[0.138]
DIA. KEEP OUT ZONE FREE OF
COPPER. ALL PCB LAYERS.
2. MINIMUM RECOMMENDED PITCH IS
39.50/[1.555].
THIS PROVIDES 7.00/[0.276] COMPONENT EDGE-TO-EDGE SPACING.
AND 0.50/[0.020] CLEARANCE BETWEEN VICOR HEAT SINKS.
3.
V•I CHIP LAND PATTERN SHOWN FOR REFERENCE ONLY;
ACTUAL LAND PATTERN MAY DIFFER.
DIMENSIONS FROM EDGES OF LAND PATTERN TO PUSH-PIN
HOLES WILL BE THE SAME FOR ALL FULL SIZE V•I CHIPS.
(mm)
4. DIMENSION ARE
inch .
NOTES:
mm
1. DIMENSIONS ARE inch .
2. UNLESS OTHERWISE SPECIFIED, TOLERANCES ARE:
.X / [.XX] = +/-0.25 / [.01]; .XX / [.XXX] = +/-0.13 / [.005]
3. PRODUCT MARKING ON TOP SURFACE
DXF and PDF files are available on vicorpower.com
TOP VIEW ( COMPONENT SIDE )
* For through–hole mechanical drawing see individual datasheets.
The products described on this data sheet are protected by the following U.S. Patents Numbers: 5,945,130; 6,403,009; 6,710,257; 6,911,848; 6,930,893; 6,934,166; 6,940,013;
6,969,909; 7,038,917; 7,166,898; 7,187,263; 7,361,844; D496,906; D505,114; D506,438; D509,472 and for use under 6,975,098 and 6,984,965
vicorpower.com
800-735-6200
Rev. 1.3
9/2009
Page 2 of 2
