TPC6503
TOSHIBA Transistor
Silicon NPN Epitaxial Type
TPC6503
High-Speed Switching Applications
DC-DC Converter Applications
Strobe Applications
•
•
•
High DC current gain: h
FE
= 400 to 1000 (I
C
= 0.15 A)
Low collector-emitter saturation voltage: V
CE (sat)
= 0.12 V (max)
High-speed switching: t
f
= 45 ns (typ.)
Unit: mm
Absolute Maximum Ratings
(Ta
=
25°C)
Characteristic
Collector-base voltage
Collector-emitter voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power
dissipation
Junction temperature
Storage temperature range
DC
t
=
10 s
DC
Pulse
Symbol
V
CBO
V
CEX
V
CEO
V
EBO
I
C
I
CP
I
B
P
C
(Note)
T
j
T
stg
Rating
40
30
20
7
1.5
2.5
150
0.8
1.6
150
−55
to 150
Unit
V
V
V
V
A
mA
JEDEC
W
°C
°C
―
―
2-3S1A
JEITA
TOSHIBA
Weight: 0.01 g (typ.)
Note: Mounted on FR4 board (glass epoxy, 1.6 mm thick, Cu area:
645 mm
2
)
Electrical Characteristics
(Ta
=
25°C)
Characteristic
Collector cut-off current
Emitter cut-off current
Collector-emitter breakdown voltage
DC current gain
Collector-emitter saturation voltage
Base-emitter saturation voltage
Collector output capacitance
Rise time
Switching time
Storage time
Fall time
Symbol
I
CBO
I
EBO
V
(BR) CEO
h
FE
(1)
h
FE
(2)
V
CE (sat)
V
BE (sat)
C
ob
t
r
t
stg
t
f
Test Conditions
V
CB
=
40 V, I
E
=
0
V
EB
=
7 V, I
C
=
0
I
C
=
10 mA, I
B
=
0
V
CE
=
2 V, I
C
=
0.15 A
V
CE
=
2 V, I
C
=
0.5 A
I
C
=
0.5 A, I
B
=
10 mA
I
C
=
0.5 A, I
B
=
10 mA
V
CB
=
10 V, I
E
=
0, f
=
1 MHz
See Figure 1 circuit diagram.
V
CC
∼
12 V, R
L
=
24
Ω
−
I
B1
= −I
B2
=
17 mA
Min
⎯
⎯
20
400
200
⎯
⎯
⎯
⎯
⎯
⎯
Typ.
⎯
⎯
⎯
⎯
⎯
⎯
⎯
18
43
295
45
Max
100
100
⎯
1000
⎯
0.12
1.10
⎯
⎯
⎯
⎯
ns
V
V
pF
Unit
nA
nA
V
1
2006-02-16
TPC6503
Transient Thermal Resistance
1000
r
th
– t
w
Transient thermal resistance
r
th
(°C/W)
100
10
Curves should be applied in thermal limited area.
この過渡熱抵抗データは熱抵抗制限領域にだけ適用されます。
Single nonrepetitive
=
25°C
単発パルス測定
Ta pulse Ta
=
25°C
Mounted on FR4
FR4
基板実装時
board (glass epoxy, 1.6 mm thick, Cu area:
2
645 mm )
(645mm
2
×
1.6 mm,
ガラスエポキシ,
Cu
面積
645 mm
2
)
1
0.001
0.01
0.1
1
10
100
1000
Pulse width
t
w
(s)
Safe operating area
10
IC max (Pulse)*
10 ms* 1 ms* 100
μs*
100 ms*
10 s*
(A)
IC max (Continuous)*
1
DC
operation
Ta = 25°C
Collector current I
C
*:
Single nonrepetitive pulse
Ta
=
25°C
Note that the curves for 100 ms,
0.1 10 s and DC operation will be
different when the device aren’t
mounted on an FR4 board (glass
epoxy, 1.6 mm thick, Cu area:
645 mm
2
).
Single-device operation
These characteristic curves must
be derated linearly with increase
in temperature.
0.01
0.1
1
VCEO max
10
100
Collector−emitter voltage V
CE
(V)
4
2006-02-16
TPC6503
