REMEC
I/Q Mixer / Modulator
Communications Band
Electrical Specifications
Parameter
SSB Conversion
loss:
(2) (3)
Image Rejection Side-
band Suppression:
(4)
Amplitude Match
Phase Match
Isolation
LO to RF:
LO to I/Q:
RF to I/Q:
I/Q to RF:
Input 1-dB
Compression Point:
Input Third Order
Intercept Point:
LO Power:
(5)
RF 5.5-13.5 GHz
LO 5.5-13.5 GHz
IF DC-500 MHz
(1)
:
Conditions
RF(GHz)
7.0-12.7
5.5-13.5
9.5-12.7
5.5-13.5
5.5-13.5
5.5-13.5
LO(GHz)
7.0-12.7
5.5-13.5
9.5-12.7
5.5-13.5
5.5-13.5
5.5-13.5
5.5-13.5
5.5-13.5
5.5-13.5
5.5-13.5
5.5-13.5
DC-500
DC-500
DC-500
DC-500
IF(MHz)
DC-500
DC-500
DC-500
DC-500
DC-500
DC-500
Min
Specifications
Typical
5.0 dB
5.3 dB
28 dB
25 dB
0.2 dB
5 deg
25 dB
35 dB
28 dB
40 dB
+5 dBm
+8 dBm
+12 dBm
+14 dBm
+17 dBm
+21 dBm
+10 dBm
+13 dBm
+17 dBm
Max
6.5 dB
7.0 dB
MIQ6xSMD-1
LO Power
4 = +10 dBm
6 = +13 dBm
7 = +17 dBm
20 dB
16 dB
5.5-13.5
5.5-13.5
5.5-13.5
5.5-13.5
20 dB
25 dB
MIQ64
MIQ66
MIQ67
MIQ64
MIQ66
MIQ67
MIQ64
MIQ66
MIQ67
Notes:
1. Specifications are guaranteed when tested as a downconverter in a 50 Ohm system at +25°C with the
nominal LO power. Specifications indicated as typical are not guaranteed.
2. Noise figure is typically within ±0.5 dB of conversion loss for IF frequencies greater than 10 MHz.
3. Conversion loss typically degrades less than 0.5 dB at +100°C and improves less than 0.5 dB at -55°C. Conversion
loss is the combined value.
4. Measured with an IF quadrature hybrid whose amplitude and phase errors are 0.5 dB and 3 degrees maximum.
An IF quadrature hybrid is not included.
5. Usable LO drives are up to 2 dB below to 3 dB above nominal.
6. See Application notes M112, for aid in selecting the outline and for mounting and installation information.
Typical Performance at 25°C
MIQ6xSMD-1
Outline: SMMC8
NOTE: See PC board footprint - FP3 on page 3-64
All dimensions are in inches and [mm].
Specifications subject to change without notice.
