All specifications are subject to change without notice.
DS 196 Rev D | 09/05/06
S1615 Series
5V CMOS Low Jitter
Crystal Clock Oscillator (XO)
Electrical Performance
Parameter
Min.
Typ.
Max.
Units
Notes
Output frequency
Supply voltage
Supply current, output enabled
Frequency stability
Operating temperature
Output logic 0, VOL
Output logic 1, VOH
1.544
+4.5
+5.0
106.25
+5.5
27
50
65
±20 to ±50
MHz
V
As specified
1.544 to 32 MHz
mA
ppM
°C
V
V
V
V
>32 to 50 MHz
>50 to 106.25 MHz
See Note 1 below
As specified
HCMOS
TTL
HCMOS
TTL
HCMOS up to <50 MHz
HCMOS 50 to <70 MHz
HCMOS 70 to 106.25 MHz
TTL
-40 to +85°C measured 50%VDD
-10 to +70°C measured 50%VDD
-40 to +85°C measured 50%VDD
-40 to +85°C measured 1.5V
measured 20/80% of waveform
-40
+85
10% V
DD
+0.4
90% V
DD
+3.9
50
30
15
10
pF
pF
pF
TTL
%
%
%
%
ns
ns
ns
ns
ns
Output load
1.544 to 80 MHz
Duty cycle
>80 to 106.25 MHz
1.544 to 106.25 MHz
1.544 up to <50 MHz
Rise and fall
time
50 to <70 MHz
70 to 106.25 MHz
1.544 to <70 MHz
70 to 106.25 MHz
45
45
40
40
55
55
60
60
8
5
3
5
2
measured 0.4V to 2.4V
Notes:
1. As specified. Stability includes all combinations of operating temperature, load changes, rated input (supply) voltage changes, initial calibration tolerance (25°C),
aging (1 year at 25°C average effective ambient temperature), shock and vibration.
