PM110 Series
7 2 - 1 1 0 W AT T S S I N G L E & M U LT I P L E O U T P U T A C / D C M E D I C A L
Features
• Low safety ground leakage current.
• Wide input range 85 to 264Vac.
• Input surge current protection.
• Overvoltage protection.
• Overcurrent protection.
• Open PCB construction.
• 100% burn-in at full rated load.
Specifications
INPUT
Input Voltage
Frequency
Input Current
Leakage current
Isolation
85–264Vac wide input
47Hz–67Hz
3.2A (rms) for 115Vac.
1.8A (rms) for 230Vac.
90µA max. @ 115Vac. 60Hz.
150µA max. @ 230Vac. 50Hz.
Input – Output: 4000VAC
Input – Ground: 1500VAC
Output – Ground: 500VAC
15A @ 115V, 30A @ 230V
OPERATING
MTBF
Efficiency
400,000 hrs @ 25°C
66%–75%
ENVIRONMENTAL
Operating Temperature
Derating
Storage Temperature
Relative Humidity
0°C to 70°C
Derate to 50% at 70°C
-40°C to 85°C
5%–95% non-condensing
STANDARDS AND APPROVALS
Safety standards
C-Tick
UL2601-1, CSA C22.2, TUV EN60601-1
AS/NZS CISPR11 Group 1, Class A
EN60601-1-2: 2001,EN61000-3-2, -3,
EN61000-4-2, -3, -4, -5, -6, -8, -11
EN55011 Class B, FCC Class B, VCCI Class B
Inrush Current
OUTPUT
Output Voltage
Output Voltage Adjustment
Output Current
Ripple & Noise
Line Regulation
Load Regulation
Transient Response
Overvoltage Protection
Overcurrent Protection
Temperature Coefficient
Holdup Time
PFD Signal
See table
V1 ±10%
See table
1% peak to peak
±0.5% maximum at full load.
See table
Max. deviation 4% recovering to 1% within
500µs after 25% load charge
Provided on V1 only. Set at 110%–132% of
nominal
All outputs protected for short circuit conditions
All outputs ±0.04% per °C
Typically 12mS at 110VAC
Power fail detection signal. TTL logic low upon
loss of input power.
EMC standards
EMI standards
MECHANICAL
Dimensions
Weight
177.8x108x47mm
640grams.
340
MEDICAL & MILITARY
PM110 Series
7 2 - 1 1 0 W AT T S S I N G L E & M U LT I P L E O U T P U T A C / D C M E D I C A L
Selection Table
MAX.
MODEL
OUTPUT #1
OUTPUT #2
(1)
OUTPUT #3
OUTPUT #4
OUTPUT
(2)
NUMBER
(1)(2)
VNOM IMIN IMAX
TOL VNOM IMIN IMAX IPEAK TOL VNOM IMIN IMAX TOL VNOM IMIN IMAX TOL POWER
PM110-10-1A
PM110-10A
PM110-12A
PM110-13A
PM110-14A
PM110-16A
PM110-23A
PM110-31A
PM110-32A
PM110-40A
PM110-41A
PM110-42A
PM110-45A
PM110-45-1A
PM110-45-2A
PM110-46A
3.3V
5V
12V
15V
24V
30V
+5.1V
+5.1V
+5.1V
+5.1V
+5.1V
+5.1V
+5.1V
+5.1V
+5.1V
+5.1V
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
2A
0A
0A
22A
22A
9.0A
7.5A
4.5A
3.6A
10A
10A
10A
10A
10A
10A
10A
10A
10A
10A
3%
3%
2%
2%
2%
2%
3%
3%
3%
3%
3%
3%
3%
3%
3%
3%
+12V
+12V
+15V
+12V
+15V
+12V
+12V
+12V
+24V
+15V
0A
0A
0A
0A
0A
0A
0A
0A
0A
0A
5A
5A
4A
5A
4A
5A
5A
5A
3A
4A
9.0A
9.0A
7.5A
9.0A
7.5A
9.0A
9.0A
9.0A
5.0A
7.5A
3%
3%
3%
3%
3%
3%
3%
3%
3%
3%
-12V
-15V
-12V
-15V
-12V
-12V
-12V
-12V
-15V
0A
0A
0A
0A
0A
0A
0A
0A
0A
1A
1A
1A
1A
1A
1A
1A
1A
1A
4%
4%
4%
4%
4%
4%
4%
4%
4%
-5V
+24V
+12V
+24V
+24V
+12V
-5V
0A
0A
0A
0A
1.5A
0A
0A
1A
1A
1A
1A
3A
1A
1A
4%
4%
4%
4%
10%
4%
4%
72W
110W
110W
110W
110W
110W
110W
110W
110W
110W
110W
110W
110W
110W
110W
110W
NOTES: (1) Peak output current with 10% maximum duty cycle for less than 60 seconds. Total peak power must not exceed 130watts.
(2) 110 watts maximum at 25CFM forced air cooling or 80 watts maximum at convection cooling, except model PM110-10-1A which is rated maximum 60
watts at convection cooling or 72 watts at 25 CFM forced air cooling.
(3) Safety agency approvals are for the above listed models in PCB mounted format. To order a model with a metallic L-bracket or box, change suffix “AL” to
“B”for L-bracket format, to “C” for enclosed format.
(4) The output #1 of model PM110-45-1A needs a minimum current of 2A to support the other outputs at their maximum rated loads.
Pin Chart
MODEL/PIN
PM110-10-1A
PM110-12A
PM110-14A
PM110-23A
PM110-31A
PM110-40A
PM110-42A
PM110-45-1A
PM110-46A
PM110-10A
PM110-13A
PM110-16A
1,2,3
Output 1
Output 1
PM110-32A
PM110-41A
PM110-45A
PM110-45-2A
Output 1
4,5
Return
Common
Return
Common
Return
Common
Return
6,7
Return
Common
Return
Common
Return
Common
Return
8,9
Output 1
Output 2
Output 2
10
P.F.D.
P.F.D.
P.F.D.
11
N.C.
N.C.
Output 3
12
Key
Key
Key
13
N.C.
N.C.
N.C.
Output 1
Output 2
P.F.D.
Output 3
Key
Output 4
Technical Illustration
