24V 2nd Gen
5 0 - 4 0 0 W
P C B
M O U N T I N G
C O M P O N E N T S
MODULES
Features
•
•
•
•
•
Input Voltage: 18-36Vdc
Output Voltage: 2-48Vdc
Output Power (per module):Maxi: 400W Micro:
100W
Efficiency: Up to 90%
Agency Approvals: UL, CSA, TUV, VDE, BABT,CE
Marked, C-Tick
Specifications
Units
Set point accuracy
Line regulation
Load regulation
Temperature regulation
Ripple and noise, p-p
Remote sense
compensation
Overvoltage set point
Current limit
Efficiency: 5V out
24Vout
Programming range
Short circuit current
Isolation voltage
(typical unless otherwise noted)
Selection Table
Notes
Nominal input; full
load; 25oC
Low line to high line;
full load
No load to full load;
nominal input
-20oC to 100oC
Full load, 20 MHz
bandwidth
OUTPUT VOLTAGE (VDC)
3.3V
5V
12V
15V
24V
28V
48V
±1% Vout nom.
±0.02% Vout nom.
±0.02% Vout nom.
±0.002% Vout/°C
100mV
0.5 Volts
115% Vout nom.
115% out max.
83%
88%
10-110% Vout nom.
115% out max.
3000Vrms
Output voltage
<250mV
Input to Output
Vout 95% of nominal
Nominal input; 80%
load; 25oC
Nominal input; 80%
load; 25oC
OUTPUT POWER (W)
MAXI
MICRO
MINI
264
150
75/50
400
400
400
400
400
400
200
200
200
200
200
200
100/50
100/50
100/50
100/50
100/50
100/50
Product Grade Specifications
E
C
T
H
M
Operating Temp. (
°C
)
-10 to 100 -20 to 100 -40 to 100 -40 to 100 -55 to 100
Storage Temp. (
°C
)
-20 to 125 -40 to 125 -40 to 125 -55 to 125 -65 to 125
Temp. Cycling
(
°C
)
Burn-In
Low Temp.Test (
°C
)
High Temp.Test (
°C
)
Final Test Data
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
24 hours
12 hours
-40°C
100°C
24 hours
24 hours
-55°C
100°C
(-55 to 125) (-65 to 125)
Mechanical Drawings refer to page 237-238
*Other O/P voltage consult sales
STANDARDS AND APPROVALS
C-Tick
AS/NZS CISPR11 Group 1 Class A
Part Numbering
24
Your dependable power partner – www.powerbox.com.au
233
