SS32-S310
SS32 - S310
Features
•
•
•
•
Metal to silicon rectifiers, majority
carrier conduction.
Low forward voltage drop.
Easy pick and place.
High surge current capability.
SMC/DO-214AB
COLOR BAND DENOTES CATHODE
Schottky Rectifiers
Absolute Maximum Ratings*
Symbol
V
RRM
I
F(AV)
I
FSM
T
stg
T
J
T
A
= 25°C unless otherwise noted
Parameter
32
Maximum Repetitive Reverse Voltage
Average Rectified Forward Current, @ T
A
= 75°C
Non-repetitive Peak Forward Surge Current
8.3 ms Single Half-Sine-Wave
Storage Temperature Range
Operating Junction Temperature
20
33
30
Value
34 35
40 50
36
60
38
80
39 310
90 100
Units
V
A
A
°C
°C
3.0
100
-55 to +150
-55 to +150
*
These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
Thermal Characteristics
Symbol
P
D
R
θJA
R
θJL
Power Dissipation
Thermal Resistance, Junction to Ambient *
Thermal Resistance, Junction to Lead
Parameter
Value
2.27
55
17
Units
W
°C/W
°C/W
*
Device mounted on FR-4 PCB 0.55 x 0.55" (14 x 14 mm).
Electrical Characteristics
Symbol
V
F
I
R
T
A
= 25°C unless otherwise noted
Parameter
32
Forward Voltage @ 3.0 A
Reverse Current @ rated V
R
T
A
= 25°C
T
A
= 100°C
33
500
20
Device
34 35
36
0.5
10
38
39
850
310
750
Units
mV
mA
mA
2001
Fairchild Semiconductor Corporation
SS32 - S310, Rev. D
SS32-S310
Schottky Rectifiers
(continued)
Typical Characteristics
Average Rectified Forward Current, I
F
[A]
3
Peak Forward Surge Current, I
FSM
[A]
150
175
100
80
2
RESISTIVE OR
INDUCTIVE LOAD
P.C.B. MOUNTED
ON 0.55 x 0.55"
(14 x 14) mm
COPPER PAD AREAS
60
40
1
20
0
0
25
50
75
100
125
Ambient Temperature [ºC]
0
1
2
5
10
20
50
Number of Cycles at 60Hz
100
Figure 1. Forward Current Derating Curve
Figure 2. Non-Repetitive Surge Current
50
T
A
= 125
º
C
20
10
SS32-SS34
T
A
= 25
º
C
SS35-S310
Forward Current, I
F
[A]
Reverse Current, I
R
[mA]
10
SS32-SS34
T
A
= 125
º
C
1
SS35-S310
1
T
A
= 150
º
C
0.1
SS32-SS34
T
A
= 75
º
C
0.1
Pulse Width = 300µS
µ
2% Duty Cycle
0.01
SS35-S310
T
A
= 25
º
C
0.01
0
0.2
0.4 0.6 0.8
1
1.2
Forward Voltage, V
F
[V]
1.4
1.6
0.001
0
20
40
60
80
100 120 140
Percent of Rated Peak Reverse Voltage [%]
Figure 3. Forward Voltage Characteristics
Figure 4. Reverse Current vs Reverse Voltage
SS32-SS34
SS35-S310
Transient Thermal Impedance [ºC/W]
100
1000
100
Total Capacitance, C
T
[pF]
10
100
1
10
0.1
1
10
Reverse Voltage, V
R
[V]
0.1
0.01
0.1
1
10
Pulse Duration [s]
100
Figure 5. Total Capacitance
Figure 6. Thermal Impedance Characteristics
SS32 - S310, Rev. D
