Chip Inductors – 0805HT Series (2012)
At just 0.035″ high, these are one of our lowest profile
surface mount inductors. Their wire wound ceramic
design provides tight tolerances, exceptional Q and
high SRF values.
Part number
1
0805HT-1N8TJL_
0805HT-2N0TJL_
0805HT-3N9TJL_
0805HT-4N3TJL_
0805HT-4N7TJL_
0805HT-5N1TJL_
0805HT-5N6TJL_
0805HT-6N8TJL_
0805HT-7N5TJL_
0805HT-8N2TJL_
0805HT-9N1TJL_
0805HT-10NT_L_
0805HT-12NT_L_
0805HT-15NT_L_
0805HT-18NT_L_
0805HT-20NT_L_
0805HT-22NT_L_
0805HT-27NT_L_
0805HT-33NT_L_
0805HT-39NT_L_
0805HT-47NT_L_
0805HT-56NT_L_
0805HT-68NT_L_
0805HT-82NT_L_
0805HT-R10T_L_
0805HT-R12T_L_
0805HT-R15T_L_
0805HT-R18T_L_
0805HT-R22T_L_
0805HT-R27T_L_
0805HT-R33T_L_
0805HT-R39T_L_
0805HT-R47T_L_
0805HT-R50T_L_
Coilcraft
Designer’s Kit C321
contains samples of all
5% parts shown as stocked. To order, contact Coil-
craft or visit
http://order.coilcraft.com
to purchase
on-line.
Q min
4
SRF min
5
(MHz)
9400
11500
6100
6364
5500
6100
5800
4800
4600
4800
3900
3300
3800
2950
3100
2700
2900
2450
2350
2200
2000
1850
1500
1500
1200
1150
1050
830
820
790
730
675
610
585
Inductance
2
(nH)
1.8
2.0
3.9
4.3
4.7
5.1
5.6
6.8
7.5
8.2
9.1
10
12
15
18
20
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
500
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 250 MHz
@ 200 MHz
@ 200 MHz
@ 200 MHz
@ 150 MHz
@ 150 MHz
@ 150 MHz
@ 150 MHz
@ 150 MHz
@ 150 MHz
@ 150 MHz
@ 150 MHz
@ 100 MHz
@ 100 MHz
@ 50 MHz
Percent
tolerance
3
5
5
5
5
5
5
5
5
5
5
5
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2,1
5,2,1
5,2,1
5,2,1
5,2,1
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
5,2
DCR max
6
(Ohms)
0.030
0.018
0.055
0.030
0.060
0.069
0.091
0.080
0.082
0.080
0.105
0.080
0.10
0.10
0.13
0.17
0.15
0.19
0.19
0.27
0.30
0.39
0.40
0.44
0.64
0.68
0.80
0.86
1.29
1.40
1.93
2.80
3.10
3.20
Irms
7
(mA)
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
800
700
600
600
600
500
500
500
400
300
300
300
200
200
200
200
200
200
Color
Code
Black
Violet
Brown
White
Red
Blue
Gray
Orange
Black
Yellow
Red
Green
Blue
Violet
Gray
Yellow
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Violet
Gray
White
Black
Orange
Yellow
Green
Blue
Violet
Gray
55 @ 1500 MHz
55 @ 1500 MHz
50 @ 1000 MHz
80 @ 1000 MHz
50 @ 1000 MHz
45 @ 1000 MHz
45 @ 1000 MHz
50 @ 1000 MHz
47 @ 1000 MHz
50 @ 1000 MHz
54 @ 1000 MHz
55 @ 750 MHz
55 @ 750 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
55 @ 500 MHz
55 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
50 @ 500 MHz
40 @ 250 MHz
40 @ 250 MHz
40 @ 250 MHz
39 @ 150 MHz
33 @ 150 MHz
32 @ 150 MHz
30 @ 150 MHz
30 @ 150 MHz
20 @ 50 MHz
1. When ordering, specify
tolerance, termination
and
packaging
codes:
0805HT-R22TGLC
Termination: L
= RoHS compliant silver-palladium-platinum-glass frit.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Tolerance:
F
= 1%
G
= 2%
J
= 5%
(Table shows stock tolerances in bold.)
Packaging: C
= 7″ machine-ready reel. EIA-481 embossed plastic
tape (2000 parts per full reel).
B
= Less than full reel. In tape, but not machine ready.
To have a leader and trailer added ($25 charge), use
code letter C instead.
D
= 13″ machine-ready reel. EIA-481 embossed plastic
tape. Factory order only, not stocked (7500 parts per
full reel).
2. Inductance measured using a Coilcraft SMD-A fixture in an Agilent/HP
4286A impedance analyzer with Coilcraft-provided correlation pieces.
3. Tolerances in bold are stocked for immediate shipment.
4. Q measured using an Agilent/HP 4291A with an Agilent/HP 16193 test
fixture and on an Agilent/HP 8753D with a Coilcraft SMD-D test fixture.
5. SRF measured using an Agilent/HP 8720D network analyzer and a
Coilcraft SMD-D test fixture.
6. DCR measured on a Cambridge Technology micro-ohmmeter and a
Coilcraft CCF858 test fixture.
7. Current that causes a 15°C temperature rise from 25°C ambient.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
Specifications subject to change without notice.
Please check our website for latest information.
Document 168-1
Revised 10/06/08
© Coilcraft, Inc. 2009
Document 168-2
0805HT Series (2012)
Typical Q vs Frequency
120
22 nH
12 nH
3.9 nH
80
150 nH
150
100
Typical L vs Frequency
200
120 nH
60
Inductance (nH)
39 nH
Q factor
100
82 nH
40
50
20
33 nH
18 nH
0
10
100
1000
10000
0
1
10
100
1000
3.9 nH
10000
Frequency (MHz)
Frequency (MHz)
Designer’s Kit C321
contains samples of all 5% tolerance parts
Core material
Ceramic
Terminations
RoHS compliant silver-palladium-platinum-glass frit.
Other terminations available at additional cost.
Weight
6.0 – 6.9 mg
Ambient temperature
–40°C to +125°C with
Irms
current, +125°C
to +140°C with derated current
Storage temperature
Component: –40°C to +140°C.
Packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Irms Derating
120
110
100
Percent of rated
I
rms
90
80
70
60
50
40
30
20
10
0
-40
-20
0
20
40
60
80
100
120 140
25°C
Ambient temperature (°C)
B
overall
F
A
G
F
E
terminal
Packaging
2000 per 7″reel; 7500 per 13″ reel;
Plastic tape: 8 mm wide, 0.23 mm thick, 4 mm pocket spacing,
0.9 mm pocket depth
PCB washing
Only pure water or alcohol recommended
C
I
J
I
Terminal wraparound:
approx 0.010/0,25 both ends
H
Recommended
Land Pattern
A
B
C
max max max
E
F
G
H
I
J
0.085 0.060 0.035 0.050 0.017 0.045 0.070 0.040 0.030
2,16
1,52
0,89
1,27
0,43
1,14
1,78
1,02
0,76
inches
mm
Specifications subject to change without notice.
Please check our website for latest information.
Document 168-2
Revised 10/06/08
© Coilcraft, Inc. 2009
