GBP3005 thru GBP310
SINGLE-PHASE SILICON BRIDGE
CHENG- YI
ELECTRONIC
VOLTAGE RANGE
50 TO 1000 VOLTS
CURRENT
3.0 Amperes
FEATURES
UL recognized file # E149311
Surge overload rating-80 amperes peak
Ideal for printed circuit board
Plastic material has Underwriters Labooratory
Flammability Classification 94V-O
Mounting position: Any
Lead: Silver Plated Cooper Lead.
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
0
C ambient temperature unless otherwise specified.
Resistive or inductive load, 60 Hz.
For capacitive load, derate current by 20%.
GBP3005 GBP301 GBP302
GBP304
400
280
400
3.0
GBP306
600
420
600
GBP308
800
560
800
GBP310
1000
700
1000
UNITS
V
V
V
A
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Output Current @
TA=25 C
0
V
RRM
V
RMS
V
DC
V
(AV)
50
35
60
100
70
100
200
140
200
Peak Forward Surge Current
8.3 ms single half sine-wave
superimposed on rated load
Maximum DC Forward Voltage
drop per element at 1.0A DC
Maximum DC Reverse Current at rated
@ TA=25 C
DC Blocking Voltage Per Element
@ TA=100 C
0
0
I
FSM
80
A
V
F
I
R
I
2
t
T
J
T
STG
1.1
10
1
10
-55 to +125
-55 to +150
V
A
mA
A
2
S
0
I
2
t Rating for fusing(t<8.3ms)
Operating Temperature Range
Storage Temperature Range
C
C
0
GBP3005 thru GBP310
SINGLE-PHASE SILICON BRIDGE
CHENG- YI
ELECTRONIC
RATING AND CHARACTERISTICS CURVES
GBP3005 THRU GBP310
Fig.2 - DERATING CURVE FOR
Fig.1 - DERATING CURVE FOR
OUTPUT RECTIFIED CURRENT
INSTANTANEOUS FORWARD CURRENT. AMPERES
20
10
OUTPUT RECTIFIED CURRENT
AVERAGE FORWARD OUTPUT CURRENT
AMPERES
3.0
2.0
1.0
1.0
TJ = 25
0
C
0.1
20
40
60
80
100
120
140
.01
0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
AMBIENT TEMPERATURE,
0
C
INSTANTANEOUS FORWARD VOLT
AGE, VOLTS
Fig.3 - TYPICAL FORWARD
CHARACTERISTICS
FIG.4 - MAXIMUM FORWARD SURGE CURRENT
10
80
PEAK FORWARD SURGE CURRENT
AMPERES
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
70
60
50
1.0
TJ=25
0
C
40
30
T J = 25
0
C
0.1
0
1
10
100
.01
0
20
40
60
80
100
120
140
NUMBER OF CYCLES AT 60 Hz
PERCENT OF RATED PEAK
REVERSE VOLTAGE
