ZMU100 thru ZMU180
Vishay Semiconductors
formerly General Semiconductor
Zener Diodes
Glass MELF
V
Z
Range
100 to 180V
Power Dissipation
1.0W
Mounting Pad Layout
0.157 (4.00)
MAX
0.049 (1.25) MIN
Cathode Mark
0.102 (2.6)
0.094 (2.4)
0.118 (3.00) MIN
0.022 (0.55)
0.205 (5.2)
0.189 (4.8)
0.256 (6.50)
REF
Dimensions in inches and (millimeters)
Mechanical Data
Case:
MELF Glass Case
Weight:
approx. 0.25g
Packaging Codes/Options:
E4/5K per 13” reel (12mm tape), 10K/box
25/1.5K per 7” reel (12mm tape), 12K/box
Features
• Silicon Planar Power Zener Diodes
• For use in stabilizing and clipping circuits with higher
power rating.
• The Zener voltages are graded according to the
international E 12 standard. Smaller voltage
tolerances are available upon request.
• These diodes are also available in the DO-41 case with
the type designation ZPU100 … ZPU180.
Ratings at 25°C ambient temperature unless otherwise specified.
Maximum Ratings & Thermal Characteristics
Parameter
Zener Current (see Table “Characteristics”)
Power Dissipation at T
amb
= 25°C
Thermal Resistance Junction to Ambient Air
Junction Temperature
Storage Temperature Range
Notes:
(1) Valid provided that electrodes are kept at ambient temperature.
Symbol
Value
1.0
(1)
170
(1)
150
–55 to +150
Unit
P
tot
R
thJA
T
j
T
S
W
°C/W
°C
°C
Electrical Characteristics
Type
Zener
Voltage
(1)
at I
ZT
V
Z
(V)
Min
ZMU100
ZMU120
ZMU150
ZMU180
88
107
130
160
Max
110
134
165
200
Ratings at 25°C ambient temperature unless otherwise specified.
Dynamic Resistance
at I
ZT
f = 1 kHz
r
Zj
(Ω)
140 (< 300)
170 (< 330)
200 (< 360)
220 (< 380)
Temp. Coeff. of
Zener Voltage at I
ZT
a
VZ
(10
–4
/°C)
Min
+9
+9
+9
+9
Max
+13
+13
+13
+13
Test current
I
ZT
(mA)
5
5
5
5
Reverse
Voltage at
I
R
= 0.5 mA
V
R
(V)
> 75
> 90
> 112
> 134
Admissible
Zener current
(2)
at T
amb
= 25°C
I
Z
(mA)
7
6
5
4
Notes:
(1) Tested with pulses t
p
= 5 ms
(2) Valid provided that electrodes are kept at ambient temperature
Document Number 88413
02-May-02
www.vishay.com
1
