PSD751S
SURFACE MOUNT ZENER DIODES
SMALL SIGNAL SCHOTTKY DIODES 30m AMPERES 40 VOLTS
SOD-523
.059(1.50)
.067(1.70)
.006(0.15)
.0098(0.25)
.0098(0.25)
.014(0.35)
.043(1.10)
.051(1.30)
.028(0.70)
.035(0.90)
1
2
.003(0.07)
.008(0.20)
.012(0.50)
.028(0.70)
FEATURES
Extremely High Switching Speed
Low Forward Voltage and Low Reverse Current
High Reliability.
Schottky Barrier Diodes Encapsulated
in a SOD-523 Package
DESCRIPTION
These schottky barrier diodes are designed for high
speed Switching applications circuit protection, and
voltage clamping, Extremely low forward voltage
reduces conduction loss, Miniature surface mount
package is excellent for hand held and Portable
applications where space is limited
MAXIMUM RATING
(T
A
=25 C unless otherwise noted)
o
CHARACTERISTICS
Peak Reverse Voltage
DC Reverse Voltage
Average Rectified Forward Current
Peak Forward Surge Current
(1)
SYMBOL
V
RM
V
R
I
F(AV)
I
FSM
T
J
T
stg
VALUE
40
30
30
200
UNITS
Volts
Volts
mA
mA
0
Operating Junction Temperature Range
Storage Temperature Range
-40 to +125
C
ELECTRICAL CHARACTERISTICS
(T
A
=25 C unless otherwise noted)
o
CHARACTERISTICS
Reverse Breakdown Voltage (I
R
= 100 A)
Forward Voltage
I
F
= 1.0mA
Reverse Leakage V
R
= 30V
Capacitance Between Terminals V
R
= 1V, f = MHz
NOTE
1. 60Hz for 1
SYMBOL
V
(BR)R
V
F
I
R
C
J
Min
30
Typ
Max
UNITS
Volts
0.37
0.5
2.0
Volts
Adc
pF
Device Marking
Item
PSD751S
Eqivalent Circuit diagram
www.paceleader.tw
