1-828205-6 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 1-828205-6

1-828205-6: DescriptionHEADER CONNECTOR,CABLE MNT,PLUG,32 CONTACTS,SKT,0.1 PITCH,IDC TERMINAL,BLACK; CategoryThe connector The connector; File Size104KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

1-828205-6 Overview

HEADER CONNECTOR,CABLE MNT,PLUG,32 CONTACTS,SKT,0.1 PITCH,IDC TERMINAL,BLACK

1-828205-6 Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Reach Compliance Code	compli
Other features	NONE
body width	0.24 inch
subject depth	0.602 inch
body length	1.6 inch
Body/casing type	PLUG
Connector type	BOARD CONNECTOR
Contactor design	PREASSEM CONN
Contact to complete cooperation	AU ON NI
Contact completed and terminated	TIN
Contact point gender	FEMALE
Contact material	PHOSPHOR BRONZE
contact mode	RECTANGULAR
Contact resistance	12 mΩ
Contact style	IDC
Dielectric withstand voltage	750VAC V
Durability	200 Cycles
maximum insertion force	2.502 N
Insulation resistance	5000000000 Ω
Insulator color	BLACK
insulator material	GLASS FILLED POLYBUTYLENE TEREPHTHALATE
Manufacturer's serial number	828205
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Installation type	CABLE
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-65 °C
Plating thickness	31u inch
Rated current (signal)	3 A
Guideline	UL, CSA
reliability	COMMERCIAL
Termination type	IDC
Total number of contacts	32
Maximum wire diameter	26 AWG
Minimum wire diameter	30 AWG
Evacuation force-minimum value	.417 N
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

PC B C onnectors

Product Feature Selector

> Product Details

1-828205-6 Product Details

Live Product Chat

Product View

.100 AMPMODU Headers, Housings & Contacts

Always EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

1-828205-6

T E I nternal N umber: 1 - 8 2 8 2 0 5 - 6

Product Highlights:

Housing

Preloaded

Number of Positions = 32

Housing Type = Receptacle

C ontact Type = Receptacle

View all Features

Pending Obsolescence

C ontact Product Information C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

None Available

Product Specifications:

C onnector, AMPMODU, Mass Terminated Standard Pressure

(PDF, English)

Interconnection System, AMPMODU MT, Shielding Access...

(PDF, English)

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Housing

Number of Positions

= 32

Mating C onnector Lock

= Without

Mating Polarization = Without

Wire Insulation Diameter (mm [in]) = 1.27 [0.050]

Keyed

= No

C onnector Series

= MT

Wire Termination Type = Insulation Displacement C rimp (IDC )

Applied Pressure = Standard

Mechanical Attachment:

Preloaded = Yes

Termination Related Features:

Solder Tail C ontact Plating = Tin

Body Related Features:

Housing Type

= Receptacle

Number of Rows

= Dual

C enterline, Matrix (mm [in])

= 2.54 x 2.54 [.100 x .100]

Wire Range (mm [AWG])

= 0.05-0.15 [30-26]

Contact Related Features:

C ontact Type = Receptacle

C ontact Mating Area Plating Material

= Gold (30)

C ontact Base Material = C opper Alloy

Housing Related Features:

Housing C olor

= Black

Housing Flammability Rating = UL 94V-0

Housing Material = Thermoplastic Polyester

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Not relevant for lead free process

RoHS/ELV C ompliance History = Always was RoHS compliant

Conditions for Usage:

Terminate To

= Wire

Other:

Brand = AMP

Additional Information:
