RoHS Compliant
E197851
19.0 x 15.5 x 15.3 mm
J107F
Features
•
•
•
•
UL F class rated standard
Small size and light weight
PC board mounting
UL/CUL certified
Contact Data
Contact Arrangement
1A = SPST N.O.
1B = SPST N.C.
1C = SPDT
Contact Rating
Specifications and availability subject to change without notice.
Contact Resistance
Contact Material
Maximum Switching Power
Maximum Switching Voltage
Maximum Switching Current
< 50 milliohms initial
AgSnO
2
2500VA, 420W
380VAC, 110VDC
20A
6A @ 277VAC;
10A @ 250VAC & 28VDC
12A @ 125VAC & 28VDC
15A @ 125VAC N.O.
20A @ 125VAC & 16VDC
1/3hp - 125/277VAC
Coil Data
Coil Voltage
VDC
Coil Resistance
Ω
+/- 10%
Pick Up Voltage Release Voltage
VDC (max)
VDC (min)
75% of rated
voltage
2.25
3.75
4.50
6.75
9.00
13.50
18.00
36.00
10% of rated
voltage
.3
.5
.6
.9
1.2
1.8
2.4
4.8
.36
.45
.80
10
5
Coil Power
W
Operate Time
ms
Release Time
ms
Rated
3
5
6
9
12
18
24
48
Max
3.9
6.5
7.8
11.7
15.6
23.4
31.2
62.4
.36W
25
70
100
225
400
900
1600
6400
.45W
20
56
80
180
320
720
1280
5120
.80W
11
31
45
101
180
405
720
2880
Dimensions shown in mm. Dimensions are shown for reference purposes only.
General Data
Electrical Life @ rated load
Mechanical Life
Insulation Resistance
Dielectric Strength, Coil to Contact
Contact to Contact
Shock Resistance
Vibration Resistance
Operating Temperature
Storage Temperature
Solderability
Weight
100K cycles, typical
10M cycles, typical
100M
Ω
min. @ 500VDC
1500V rms min. @ sea level
750V rms min. @ sea level
100m/s
2
for 11 ms
1.50mm double amplitude 10~40Hz
-55
o
C to +125
o
C
-55
o
C to +155
o
C
260
o
C for 5 s
9.5g
www.citrelay.com
phone - 763.535.2339
fax - 763.535.2194
Caution
1. The use of any coil voltage less than the
rated coil voltage may compromise the
operation of the relay.
J107F
Ordering Information
1. Series
J107F
2. Contact Arrangement
1A = SPST N.O.
1B = SPST N.C.
1C = SPDT
3. Sealing Option
S = Sealed
4. Contact Rating
12 = 12A
15 = 15A
20 = 20A (20Amp available in .45 or .80 watt coil only)
Dimensions shown in mm. Dimensions are shown for reference purposes only.
J107F
1C
S
12
12VDC
.36
5. Coil Voltage
3VDC
5VDC
6VDC
9VDC
12VDC
18VDC
24VDC
48VDC
6. Coil Power
.36 = .36W
.45 = .45W
.80 = .80W
Dimensions
Units = mm
Specifications and availability subject to change without notice.
Schematics & PC Layouts
Bottom Views
1A
www.citrelay.com
phone - 763.535.2339
fax - 763.535.2194
1B
1C
