MKT 1813
Vishay Roederstein
Metallized Polyester Film Capacitor
Related Document: IEC 60384-2
Dimensions in millimeters
Ød
FEATURES
Product is completely lead (Pb)-free
Product is RoHS compliant
D
Max.
40.0
±
5.0
L
Max.
40.0
±
5.0
RATED VOLTAGES (U
R
)
63 VDC, 100 VDC, 250 VDC, 400 VDC, 630 VDC,
1000 VDC
e3
RoHS
d
0.6
0.7
0.8
1.0
D
≤
5.0
> 5.0
≤
7.0
> 7.0 < 16.5
≥
16.5
PERMISSIBLE AC VOLTAGES (RMS) UP TO
COMPLIANT
60Hz
40 VAC, 63 VAC, 160 VAC, 200 VAC, 220 VAC, 220 VAC
INSULATION RESISTANCE
Measured at 100 VDC (63 VDC series measured at 50 VDC)
after one minute
For C
≤
0.33µF and U
R
> 100 VDC
30,000 MΩ minimum value (60,000 MΩ typical value)
For C
≤
0.33µF and U
R
≤
100 VDC
15,000 MΩ minimum value (50,000 MΩ typical value)
TIME CONSTANT
Measured at 100 VDC (63 VDC series measured at 50 VDC)
after one minute
For C > 0.33µF and U
R
> 100 VDC
10,000 s minimum value (20,000 s typical value)
For C > 0.33µF and U
R
≤
100 VDC
5000 s minimum value (15,000 s typical value)
CAPACITANCE DRIFT
Up to + 40°C, ± 1.5% for a period of two years
DERATING FOR DC AND AC. CATEGORY VOLTAGE U
C
At + 85°C: U
C
= 1.0 U
R
At + 100°C: U
C
= 0.8 U
R
SELF INDUCTANCE
~ 12nH measured with 6mm long leads
PULL TEST ON LEADS
≥
20 N in direction of leads according to IEC 60068-2-21
BEND TEST ON LEADS
Two bends through 90°C with half of the force used in pull
test
RELIABILITY
Operational life > 300,000 h
Failure rate < 2 FIT (40°C and 0.5 x U
R
)
For further details, please refer to the general information
available at www.vishay.com/doc?26033.
MAIN APPLICATIONS
Blocking, bypassing, filtering, timing, coupling and
decoupling, interference suppression in low voltage
applications.
MARKING
Manufacturer's logo/type/C-value/rated voltage/tolerance/
date of manufacture
DIELECTRIC
Polyester film
ELECTRODES
Vacuum deposited aluminum
COATING
Plastic-wrapped, epoxy resin sealed. Also available as
flame retardant version.
CONSTRUCTION
Extended metallized film (refer to general information)
LEADS
Tinned wire
IEC TEST CLASSIFICATION
55/100/56, according to IEC 60068
OPERATING TEMPERATURE RANGE
- 55°C to + 100°C
CAPACITANCE RANGE
470pF to 22µF
CAPACITANCE TOLERANCES
± 20% (M), ± 10% (K), ± 5% (J)
TEST VOLTAGE (ELECTRODE/ELECTRODE)
1.6 x U
R
for 2 s
MAXIMUM PULSE RISE TIME
CAPACITOR
Maximum Pulse Rise Time d
v
/d
t
[V/µs]
LENGTH (mm)
63 VDC
100 VDC
250 VDC
400 VDC
11
12
18
32
56
14
11
13
22
37
19
7
8
13
21
26.5
4
5
8
13
31.5
3
4
6
10
41.5
2
3
5
7
If the maximum pulse voltage is less than the rated voltage higher d
v
/d
t
values can be permitted.
Document Number: 26013
Revision: 22-Jun-05
For technical questions contact; dc-film@vishay.com
630 VDC
84
66
33
19
15
10
1000 VDC
—
175
65
34
25
17
www.vishay.com
1
MKT 1813
Vishay Roederstein
Metallized Polyester Film Capacitor
Related Document: IEC 60384-2
VRMS
VRMS
100
7
5
3
2
10
7
5
3
2
1
10
2
63 VDC
2
3
5 7
10
3
2
3
22
Capacitance in
µF
0.1
5
0.3
3
0.4
7
100
7
5
3
2
0.0
68
0.1
Capacitance in
µF
5
0.2
2
0.4
7
1
2.2
4.7
15
10
1.0
4.7
2.2
10
7
5
3
2
5 7
10
4
2
3
5 7
f [Hz]
10
5
1
10
2
100 VDC
2
3
5 7 10
3
2
3
5 7 10
4
2
3
15
Permissible AC Voltage versus Frequency
Permissible AC Voltage versus Frequency
5 7 10
5
f [Hz]
1000
7
5
3
2
100
7
5
3
2
10
10
2
250 VDC
2
3
5 7 10
3
2
3
5 7
0.0
15
0.0
10
4.7
2.2
1.0
0.3
3
VRMS
Capacitance in
µF
1000
7
5
3
2
100
7
5
0.0
06
8
0.0
2.
2
VRMS
Capacitance in
µF
47
0.1
22
0.0
47
5
3
2
2
3
5 7
f [Hz]
10
5
10
10
2
400 VDC
2
3
5 7 10
3
1.0
0.4
7
0.2
2
0.1
10
4
2
3
5 7 10
4
2
3
Permissible AC Voltage versus Frequency
5 7 10
5
f [Hz]
Permissible AC Voltage versus Frequency
1000
7
5
3
2
100
7
5
3
2
10
10
2
630 VDC
2
3
5 7 10
3
2
VRMS
Capacitance in pF and
µF
1000
7
5
3
2
VRMS
Capacitance in pF and
µF
0.0
1
0.0
0.0
33
47
0
10
0
0.1
0.2
2
0.4
7
0.0
04
7
0
22
00
47
00
0.0
02
2
0.0
01
0.1
1.0
0.2
2
100
7
5
3
2
47
0.0
22
0.0
1
3
5 7 10
4
2
3
5 7 10
5
f [Hz]
10
1000 VDC
10
2
2
3
5 7 10
3
2
3
5 7 10
4
2
3
5 7 10
5
f [Hz]
Permissible AC Voltage versus Frequency
Permissible AC Voltage versus Frequency
www.vishay.com
4
For technical questions contact; dc-film@vishay.com
Document Number: 26013
Revision: 22-Jun-05
