GB-B336 SERIES
Blinking, Round Type
LED Lamps (5mm)
DESCRIPTION:
The B336 series with built-in I.C. which flashes the lamp on or off, can be driven
directly by standard TTL and CMOS circuits without the need for external
switching circuit.
The semi-conductor materials used are:
GaP for (B336VGC/VGD)
GaAlAs for (B336HR3C/HR3D, B336UR1C/UR1D)
GaAsP/GaP for ( B336VYC/VYD )
PACKAGE DIMENSIONS
Unit: mm
Tol: +/- 0.2mm
5.9
φ5.0
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Reverse Voltage
Reverse Current (Vr =5V)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
(1.6mm (1/16)From Body)
5 Volt
100µA
o
-40 C To 85
o
C
o
o
-40 C To 100 C
o
260 C For 5 Seconds
1.0 Max.
1.0
o
8.6
25.4 Min.
0.5
1.0
2.54
NOTES : 1. All dimensions are in millimeters.
2. Lead spacing is measured where the leads emerge from the package.
3. Protuded resin under flange is 1.5 mm (0.059") Max.
4. Specifications are subject to change without notice.
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Part No.
Emitted
Color
Super Red
Super Red
Lens
Color
Red Diffused
Red Diffused
Output
Operating
Peak
Sink
Voltage
Rec.
Wavelength
Min Max If (mA). Current
λp
(nm)
Typ (mA)
(V)
660
660
565
585
660
660
565
585
3.0
3.0
3.0
3.0
3.0
3.0
3.0
3.0
10
10
10
10
10
10
10
10
10-20
10-20
10-20
10-20
10-20
10-20
10-20
10-20
35
35
45
45
35
35
45
45
Output
Source
Current
Typ (mA)
25
25
25
25
25
25
25
25
Blinking
Frequency
Min
Max
(Hz)
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.0
2.8
2.8
2.8
2.8
2.8
2.8
2.8
2.8
View
Angle
2θ
1/2
(Deg)
40
40
40
40
20
20
20
20
o
GB-B336HR3D
GB-B336UR1D
GB-B336VGD
GB-B336VYD
GB-B336HR3C
GB-B336UR1C
GB-B336VGC
GB-B336VYC
Super Green Green Diffused
Super Yellow Yellow Diffused
Super Red
Super Red
Super Green
Super Yellow
Water Clear
Water Clear
Water Clear
Water Clear
TESTING CONDITION FOR EACH PARAMETER :
PARAMETER:
REVERSE VOLTAGE
REVERSE CURRENT
OUTPUT SINK CURRENT
OUTPUT SOURCE CURRENT
BLINKING FREQUENCY
RECOMMENDED OPERATING CURRENT
SYMBOL
Vr
Ir
I
sink
I
source
F
blk
If (Rec)
UNIT
VOLT
µA
mA
mA
Hz
mA
TEST CONDITION
Vr = 5.0 Volt
If = 20mA
If = 20mA
If = 20mA
0
o
10
o
20
o
30
o
C
D
1.0
0.9
0.8
60
o
0.7
70
o
40
o
50
o
80
o
90
o
0.5
0.3
0.1
0.2
0.4
0.6
SPATIAL DISTRIBUTION
