Oval Type
Wide Angle
LED Lamps (4.7 x 5.7mm)
DESCRIPTION:
The 623 series is oval type specially designed for full color video and information
signs. These devices are excellent for outdoor application where a wide viewing
angle and readability in sunlight are essential.
The semi-conductor materials used are:
GaP for (623HD/HT, 623GC/GD/GT)
GaAsP/GaP for (623RHC/RHD/RHT, 623YC/YD/YT and 623SD)
GB-623 SERIES
PACKAGE DIMENSIONS
Unit: mm
Tol: +/- 0.2mm
5.7
4.7
ABSOLUTE MAXIMUM RATINGS: (Ta=25 C)
Reverse Voltage
Reverse Current (Vr =5V)
Operating Temperature Range
Storage Temperature Range
Lead Soldering Temperature
(1.6mm (1/16)From Body)
5 Volt
100µA
o
o
-40 C To 85 C
o
o
-40 C To 100 C
o
260 C For 5 Seconds
1.0 Max.
o
7.9
25.4 Min.
0.5
1.0
2.54
NOTES : 1. All dimensions are in millimeters.
2. Lead spacing is measured where the leads emerge from the package.
3. Protuded resin under flange is 1.5 mm (0.059") Max.
4. Specifications are subject to change without notice.
PART NO. SELECTION AND APPLICATION INFORMATION (RATINGS AT 25 C AMBIENT)
Emitted
Color
Red
Bright Red
Green
Yellow
Orange
Red
Bright Red
Green
Yellow
Bright Red
Green
Yellow
Lens
Color
Red Diffused
Red Diffused
Green Diffused
Yellow Diffused
Orange Diffused
Red Trans.
Red Trans.
Green Trans.
Yellow Trans.
Water Clear
Water Clear
Water Clear
Peak
Wavelength
λp
(nm)
697
660
565
585
610
697
660
565
585
660
565
585
Vf (v)
Min Max
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
1.7
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
2.6
Rec.
If (mA).
5-10
10-20
10-20
10-20
10-20
5-10
10-20
10-20
10-20
10-20
10-20
10-20
Iv (mcd)
Min Typ.
1.0
2.5
2.5
2.5
2.5
1.0
6.0
6.0
6.0
6.0
6.0
6.0
3.0
10.0
10.0
10.0
10.0
15.0
30.0
30.0
30.0
30.0
30.0
30.0
View
Angle
2θ
1/2
(Deg)
X-AXIS = 76
Y-AXIS = 35
X-AXIS = 76
Y-AXIS = 35
X-AXIS = 76
Y-AXIS = 35
X-AXIS = 76
Y-AXIS = 35
X-AXIS = 76
Y-AXIS = 35
X-AXIS = 54
Y-AXIS = 25
X-AXIS = 54
Y-AXIS = 25
X-AXIS = 54
Y-AXIS = 25
X-AXIS = 54
Y-AXIS = 25
X-AXIS = 54
Y-AXIS = 25
X-AXIS = 54
Y-AXIS = 25
X-AXIS = 54
Y-AXIS = 25
o
Part No.
GB-623HD
GB-623RHD
GB-623GD
GB-623YD
GB-623SD
GB-623HT
GB-623RHT
GB-623GT
GB-623YT
GB-623RHC
GB-623GC
GB-623YC
TESTING CONDITION FOR EACH PARAMETER :
PARAMETER:
REVERSE VOLTAGE
REVERSE CURRENT
FORWARD VOLTAGE
LUMINOUS INTENSITY
VIEWING ANGLE
RECOMMENDED OPERATING CURRENT
SYMBOL
Vr
Ir
Vf
Iv
2θ
1/2
If (Rec)
UNIT
VOLT
µA
VOLT
MCD
DEGREE
mA
TEST CONDITION
Vr = 5.0 Volt
If = 20mA
If = 20mA
If = 20mA
C,T(X-AXIS)
C,T(Y-AXIS)
0
o
10
o
20
o
D(X-AXIS)
30
D(Y-AXIS)
40
o
o
1.0
0.9
0.8
50
o
60
o
0.7
70
o
80
o
90
o
0.5
0.3
0.1
0.2
0.4
0.6
SPATIAL DISTRIBUTION
