Amphenol
Cable
Twist ‘n’ Flat
®
1.27mm Twisted Pair Ribbon Cable
Combines the time and cost savings of mass termination with the electrical performance of twisted pairs.
132 Series
Ribbon Cable
Materials
Pitch
Reel Length
Conductor
Insulation
Laminate
Temperature
Twisted Length
Flat Length
– 1.27mm
– 100 ft
– 28AWG (7/36 strand)
Tinned Copper
– PVC
– Clear PVC
– 80˚C
– ± 457.2mm
– ± 50.8mm
152 Series
Shielded Cable
159 Series
Round Cable
Materials
Pitch
Reel Length
Conductor
Insulation
Shield
Drain wire
Jacket
Laminate
Temperature
Twisted Length
Flat Length
– 1.27mm
– 100 ft
– 28AWG (7/36 strand)
Tinned Copper
– PVC
– Aluminum/Poly
– 28AWG (7/38 strand)
Tinned Copper
– Extruded black PVC
– Clear PVC
– 80˚C
– ± 457.2mm
– ± 50.8mm
Materials
Pitch
Reel Length
Conductor
Insulation
Shield
– 1.27mm
– 100 ft
– 28AWG (7/36 strand)
Tinned Copper
– PVC
– Aluminum/Poly Foil
– with 85% covered
Tinned Copper braid
– Black PVC
– Clear PVC
– -20˚C to 105˚C
– ± 444.5mm
– ± 63.5mm
Electrical
Current
– 1A
Voltage
– 300V
Impedance
– 100Ω
Capacitance
– 15 pf/ft nom.
Crosstalk (10’ sample, 5ns rise time)
Unbalanced
– NE= 4%, FE = 3.5%
Balanced
– NE = .7%, FE = .45%
Propagation delay – 1.6ns/ft nom.
Jacket
Laminate
Temperature
Twisted Length
Flat Length
Electrical
Current
– 1A
Voltage
– 300V
Impedance
– 75Ω
Capacitance
– 22 pf/ft nom at 1MHz
Crosstalk (10’ sample, 5ns rise time)
Unbalanced
– NE= 4%, FE = 3.5%
Balanced
– NE = .7%, FE = .45%
Propagation delay – 1.6ns/ft nom.
Electrical
Current
– 1A
Voltage
– 300V
Impedance
– 70Ω
Capacitance
– 25 pf/ft nom at 1MHz
Crosstalk (10’ sample, 5ns rise time)
Balanced
– NE = 2.3%, FE = 1.3%
Propagation delay – 1.65ns/ft nom.
Features
Allows for mass termination
Up to 32 pairs (64 conductors)
Highly flexible colour coded
Features
Up to 32 pairs (64 conductors)
Highly flexible colour coded
Meets FFC regulations
Features
EMI/RFI Shielded
Highly flexible colour coded
Part Number:
843-132-2801-010
843-132-2801-014
843-132-2801-016
843-132-2801-020
843-132-2801-026
843-132-2801-034
843-132-2801-036
843-132-2801-040
843-132-2801-050
843-132-2801-060
843-132-2801-064
No. of
Pairs
5
7
8
10
13
17
18
20
25
30
32
Dimensions
A
B
13.36
11.43
18.44
16.51
20.98
19.05
26.06
24.13
33.68
31.75
43.84
41.91
46.38
44.45
51.46
49.53
64.16
62.23
76.86
74.93
81.94
80.01
Part Number:
843-152-2831-010
843-152-2831-014
843-152-2831-016
843-152-2831-020
843-152-2831-026
843-152-2831-034
843-152-2831-040
843-152-2831-050
843-152-2831-060
No. of
Pairs
5
7
8
10
13
17
20
25
30
Dimensions
C
B
14.99
11.43
20.01
16.51
22.61
19.05
27.69
24.13
35.31
31.75
45.47
41.91
53.09
49.53
65.79
62.23
78.49
74.93
Part Numbers:
843-159-2832-010
843-159-2832-014
843-159-2832-016
843-159-2832-020
843-159-2832-026
843-159-2832-034
843-159-2832-040
843-159-2832-050
843-159-2832-060
843-159-2832-064
No. of
Pairs
5
7
8
10
13
17
20
25
30
32
Dimensions
Outer Ø
7.62
8.38
8.64
9.65
10.41
11.43
12.19
13.46
14.48
14.73
Twist ‘N’ Flat configuration the same as 132 Series
Alternate Twist N Flat Cable
Halogen-free (Flame Retardant) 132-2829-0XX
–65~150˚C Halogen-free 132-2821-0XX
Halogen-free Loose Pair 468-2829-0XX*
SS
Alternate Jacketed Twist N Flat Cable
No Shield, No Drain 843-152-2811-0XX
Copper Mesh Shield 843-152-2821-0XX
Alternate Twist N Flat Round Cable
No Braid, Shielded 843-159-2832-1XX
No Braid, No Shield 843-159-2832-2XX
Loose Pair Shielded 169-2832-0XX*
Halogen-free Loose Pair Shielded 168-2829-0XX*
–65~150˚C Halogen-free 168-2832-0XX*
T-3
