TERMINATIONS

TNC, DC - 1

2.4 GHz, 5 Watts

SPECIFICATIONS:

Models: 3073TM, 3073TF, 3073TMC, 3073TFC

Electrical:

Frequency Range

VSWR:

DC - 4 GHz

4 - 8 GHz

8 - 1 GHz

2.4

Impedance

Input Power

Peak Power

Operating Temp Range

DC - 1 GHz

2.4

1. 0:1 Max.

1

1. 5:1 Max.

1

1.20:1 Max.

50 Ohms

5 Watts Avg. @ +25°C

Derated Linearly to 1 Watt @ +1

o

C

25

5 kW Max.

(5uSec Pulse, .05% Duty Cycle)

3.5 [89] Long

Bead Chain

-65°C to +125°C

Ø.13[3.3]

Thru

Mechanical:

TNC Connectors

Mates with MIL

-STD-348

Passivated Stainless Steel

Anodized Aluminum

Gold Plated Beryllium Copper

Passivated Stainless Steel

Housing

Conductors

Bead Chain

CHAIN DETAIL

Model Number:

3073TF

TNC Female Connector

1.78±.05

[45.21±1.27]

Ø.75

[19.05]

Model Number:

3073TM

TNC Male Connector

1.68±.05

[42.67±1.27]

Ø.75

[19.05]

HOW TO ORDER:

Model Number:

Ordering Examples:

3073TXY

Style

= No Chain

C = Chain Included

Connector Configuration

M = Male

F = Female

Model Number:

3073TMC

DC - 1 GHz; TNC N Male; Chain Included

2.4

Model Number:

3073TF

DC - 1 GHz; TNC N Female; No Chain

2.4

Model Number:

3073TM

DC - 1 GHz; TNC N Male: No Chain

2.4

Note: Dimensions in Brackets are Expressed in Millimeters and are for Reference Only.

Design, specifications are subject to change without notice. Contact factory for technical

specifications before purchasing and/or use.

3037T: REV -

Aeroflex / Inmet, Inc.

300 Dino Drive, Ann Arbor, MI 48103 • U.S.A.

888-244-6638 or 734-426-5553 • FAX: 734-426-5557

www.aeroflex.com/inmet
