UBMINIATURE
S
UBMINIATURE
F
USEHOLDERS
Holder / No. 560
PC Mount,
for TR5
®
/TE5
®
Fuses
∅
9,5
Specifications
Packaging
1
bulk (1000 pcs.)
0
bulk (500 pcs.)
Order Number
Holder
No. 560 0000 13 1
Holder
No. 560 0000 10 0
Holder
No. 560 0000 10 1
Mounting
PC Board, 5.08 mm pin spacing
Materials
Holder:
Thermoplastic, UL 94 V-0
Polyester PCT
Metal parts: Copper alloy; solderable tinned
“A”
3.0 mm
4.3 mm
code
height
13
10
1,35
∅
0,5
5,08
Holes in PCB
5,08
1 +0,1
45
3
1,3
∅
1
A
R0,75
Electrical Data (23 ºC)
Rated Voltage:
250 V
Max. Current/Power: 6.3 A/1.6 W
Solderability
max. 280 ºC, 10 s (Wave)
WebLinks
Further info see:
www.wickmanngroup.com
Minimum Cross Section
Conducting path - 0.1 mm
2
Unit Weight
0,4 g
Further application info see fuseology:
www.wickmanngroup.com/download/
fuseology.pdf
Order
Information
Qty.
Order-
Number
Series
560
code height
Packaging
Specifications are subject
to change without notice
0000
Holder / No. 559
PC Mount,
for TR5
®
/TE5
®
Fuses
leadfree
∅
10
6,5
0,9
1,2
R0,3
7,18
Packaging
000
bulk (1000 pcs.)
Mounting
PC Board, 7.18 mm pin spacing
Materials
Holder:
Metal parts:
Black Thermoplastic, UL94 V-0
Polyamide PA 6.6
Copper alloy; solderable
tinned
3,8
Electrical Data (23 ºC)
Rated Voltage:
250 V
Max. Current/Power: 6.3 A/1.6 W
0,5
Solderability
Holes in PCB
1,3 +0,1
max. 260 ºC, 10 s (Wave)
7,18
1 +0,1
5,2-0,1
Minimum Cross Section
Conducting path - 0.1 mm 2
Unit Weight
0.63 g
W ebLinks
Further infos see:
www.wickmanngroup.com
Further application infos see
Fuseology:
www.wickmanngroup.com/download/
fuseology.pdf
Order
Information
Qty.
Order-
Number
Series
559
0000
Packaging
000
Specifications are subject
to change without notice
050201
WebSite
www.wickmanngroup.com
Europe
Tel: +49 2302 662-107
E-mail: sales@wickmann.com
Americas
Tel: +1 404 699-7820
E-mail: service@wickmannusa.com
Asia
Tel: +852 26 14-1108
E-mail: sales@wickmann.com.hk
China
Tel: +86 21 6432 5146
E-mail: sales@wickmann.cn
