INIATURE
M
INIATURE
F
USEHOLDERS
Not for new designs;
please refer to holder no. 831/834
Holder / No. 598
PC Mount,
for 5x20mm and 5x25mm
Fuses
Kappe eingesetzt
Specifications
Montage
(2) Solder pins0.5 x 1.1mm
IP 40 (IEC 60529)
Holder:
Cap:
Protection Class & Category
Materials
Duroplastic
(Phenolplast PF), black
Thermoplastic (Polyamide
PA 6.6), UL 94 V-0, black
Copper alloy,
corrosion protected
solderable tinned
M8x0,75
a
7,5
Metal Parts:
Terminals:
27
±0,5
13
±0,3
12
±0,3
Electrical Data (23 ºC)
Rated Voltage:
250 V
max. Current/Power: 6.3 A / 2.5 W
-25 °C to 70 °C (consider de-rating)
10 °C to 60 °C
≤
5 mΩ
5
0,5
Löcher in Leiterplatte ø 1,3
+0,1
Holes in the pcb
ø 1,3
+0,1
12,5
12,5
2
Operating Temperature
Temperature
Leiterplatte
Printed circuit board
1,1
10
=
10
=
Stock Conditions
Contact Resistance
Dielectric Strength
3 kV, 50Hz, 1 min., dry
Holes in the Printed Circuit Board
Insulation Resistance
for fuses 5 x 20 mm
Schlitz für Münze Breite 1,8
Slot for coin width 1,8
-0,5
Cap / No. 585
> 10
3
MΩ (500 V DC, 1 min.)
235 ºC, 3 sec. (Wave)
350 ºC, 1 sec. (Soldering Iron)
260 °C, 5 sec.
ø11
±0,2
Solderability
Soldering Heat Resistance
Minimum Cross Section
ø8,4
±0,1
18,5
Conduction Path - 0.2mm
2
598, 250 V
9
±0,5
Marking
Unit weight
4,2
±0,2
M8x0,75
4,9 g (598) / 3,6 g (585) / 3,4 g (586)
for fuses 5 x 25 mm
Schaufenster PC farblos, glasklar
(für Kennmelder-Sicherung)
Window PC transparent, clear
(For indicator fuse)
19,5
-0,5
Cap / No. 586
ø11
±0,2
ø8,4
±0,1
9
±0,5
Order Information
Packaging
Bulk (100 St.)
Holder
Cap, 5 x 20 mm
Cap, 5 x 25 mm
No. 598 0000 000
No. 585 0000 000
No. 586 0000 000
Order Numbers
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
