INIATURE
M
INIATURE
F
USEHOLDERS
Holder / No. 595
not for new developments;
please refer to holder no. 850
2
±0,2
Panel Mount,
for 5x20 mm Fuses
22,7
1
±0,1
Specifications
Montage
+0,1
12.7mm diameter D-hole
Admissible torque on plastic hex nut is 1.2Nm
Solderable or 2.8mm quick connect-fits 0.5mm tab
IP 40 (IEC 60529)
Holder:
Cap:
Metal Parts:
+0,3
-0,2
1
+0,3
2,8
1,7
±0,05
7,1
Te r m i n a l s
Protection Class & Category
±0,15
0,5
ø15
+0,05
Materials
Gerätewand
panel
M12,7x1,5
-0,1
ø12,7
SW14
Terminals:
Duroplastic
(Phenolplast PF), black
Thermoplastic (Polyamide
PA 6.6), UL 94 V-0, black
Copper alloy,
corrosion protected
solderable tinned
3,2
Electrical Data (23 ºC)
12
-0,1
2
±0,1
3,5
Rated Voltage:
250 V
max. Current/Power: 6.3 A / 2.5 W
-25 °C to 70 °C (consider de-rating)
10 °C to 70 °C
≤
5 mΩ
Temperature
Operating Temperature
Stock Conditions
Contact Resistance
Dielectric Strength
3 kV, dry
Holes in the Printed Circuit Board
Cap / No. 583
15,7
-0,2
Insulation Resistance
Solderability
±0,4
> 10
3
MΩ (500 V DC, 1 min.)
235 ºC, 3 sec. (Wave)
350 ºC, 1 sec. (Soldering Iron)
260 °C, 5 sec. (IEC 60068.2-20)
595, 250 V
3,4 g (595) / 1,7 g (583)
ø10,3
Renknase
Bayonet-connector-nose
8,5
±0,5
Soldering Heat Resistance
Marking
Unit weight
Schlitz für Schraubendreher
Slot for screw-driver
Order Information
Packaging
Bulk (100 St.)
Holder
Cap
No. 595 0000 000
No. 583 0000 000
Order Numbers
Note: 1.00 means the number one with two decimal places. 1,000 means the number one thousand.
050909
In our continuing strategy to deliver unparalleled circuit protection solutions,
technical expertise and application leadership, we proudly introduce the
WICKMANN Group and its products to the Littelfuse portfolio.
