COMMUNICATIONS COMPONENTS
Fused Coupler, Single Window
Key Features
• Wide wavelength coverage over multiple bands
• High power handling
• Wide range of regular parts available "to go"
• Proven reliability
Applications
• Passive optical networks
• CATV
• Network expansion
• Fixed attenuation (select
configuration option 0)
The single window fused coupler splits or combines light with high performance
over a wide bandwidth. These components are manufactured with a highly
automated process to achieve consistent quality and reliability.
Regular parts are available with a wide variety of tap ratios, operating
wavelengths, housing and connector options and can therefore be readily
specified in a wide variety of applications, enabling rapid design cycles and new
project builds. Reliability is assured through qualification to Telcordia GR-1221.
Compliance
• Telcordia GR-1221
Dimensions Diagram: 1x2 Model, H-Package
(Specifications in mm unless otherwise noted. 3mm cable shown.)
20.3 mm
(2x) R2.5 mm
44.5 mm
2.0 mm
3.4 mm
Typ.
(3x) Ø3.0 mm
17.8 mm
(2x) Ø2.0 mm
3.5 mm
7.1 mm
85.0 mm
7.5 mm
NORTH AMERICA
:
800 498-JDSU (5378)
WORLDWIDE
:
+800 5378-JDSU
WEBSITE
:
www.jdsu.com
FUSED COUPLER, SINGLE WINDOW
2
Wavelength Stability: 1550 nm 1/99 Port 2 (1%)
Wavelength Stability: 1550 nm 10/90 Port 2 (10%)
Wavelength Stability: 1550 nm 50/50 Port 2 (50%)
Qualification and Reliability Tests
Parameter
High temperature storage test
Damp heat test
Water immersion test
Vibration test
Shock test
Impact test
Fiber torsion test
Fiber pulling test
INSERTION LOSS (dB)
INSERTION LOSS (dB)
Specifications
85 °C for 2,000 hours
50 °C/90% RH for 2,000 hours
43±2 °C, pH of 5.5±0.5 for 7 days
10 to 2,000 Hz, 20 g’s, 3 axes
3 axes, 40 g’s, 11 ms, 5 blows each direction
1.8 meters height, 8 times
180° twist, 5 times both directions, 5 N force
5 N for 1 minute
INSERTION LOSS (dB)
FUSED COUPLER, SINGLE WINDOW
3
Insertion Loss
Coupling Ratio
Attenuation
Grade
Signal Path
Insertion Loss (Min./Max.)
NA/0.2 dB
NA/0.3 dB
NA/0.2 dB
NA/0.3 dB
NA/0.3 dB
NA/0.4 dB
NA/0.4 dB
NA/0.5 dB
0.4/0.6 dB
0.3/0.8 dB
0.9/1.2 dB
0.8/1.3 dB
1.4/1.8 dB
1.3/2 dB
1.6/2.1 dB
1.4/2.3 dB
2/2.5 dB
1.8/2.8 dB
2.7/3.4 dB
2.6/3.6 dB
Tap Path (or Attenuator Path)
Insertion Loss (Min./Max.)
17.4/21.5 dB
15/22 dB
16.4/19 dB
15.3/18.2 dB
14.5/17.5 dB
12.8/19.5 dB
11.8/14.6 dB
10.6/18.9 dB
9.6/10.8 dB
8.3/12 dB
6.5/7.4 dB
6.2/8 dB
4.9/5.6 dB
4.5/6.1 dB
4.4/5.2 dB
4/5.7 dB
3.7/4.4 dB
3.3/4.8 dB
2.7/3.4 dB
2.6/3.6 dB
1%
1%
2%
2%
3%
3%
5%
5%
10%
10%
20%
20%
30%
30%
33%
33%
40%
40%
50%
50%
20 dB
20 dB
17 dB
17 dB
15 dB
15 dB
13 dB
13 dB
10 dB
10 dB
7 dB
7 dB
5.2 dB
5.2 dB
4.8 dB
4.8 dB
4 dB
4 dB
3 dB
3 dB
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
Specifications
Parameter (50/50 coupling ratio)
Center wavelength
Insertion loss (without connectors)
Excess loss (without connectors)
Uniformity
Polarization dependent loss
Optical return loss
Directivity
Temperature coefficient
Package dimensions
S package (D x L)
L package (D x L)
H package (L x W x H)
Operating temperature
1
Storage temperature
1
1.
20 to 70 °C for 3.0 mm cable
Grade 1
1310, 1480, 1550, 1590 nm
3.4 dB
0.1 dB
0.6 dB
0.1 dB
50 dB
55 dB
0.002 dB/°C
3.0 x 54 mm
3.6 x 70 mm
85 x 17.8 x 7.5 mm
-40 to 85 °C
-50 to 85 °C
Grade 2
1310, 1480, 1550, 1590 nm
3.6 dB
0.3 dB
1.0 dB
0.15 dB
50 dB
55 dB
0.002 dB/°C
3.0 x 54 mm
3.6 x 70 mm
85 x 17.8 x 7.5 mm
-40 to 85 °C
-50 to 85 °C
Maximum
Typical
Maximum
Maximum
Minimum
Minimum
Typical
FUSED COUPLER, SINGLE WINDOW
Ordering Information
For more information on this or other products and their availability, please contact your local JDSU account manager or
JDSU directly at 1-800-498-JDSU (5378) in North America and +800-5378-JDSU worldwide or via e-mail at
customer.service@jdsu.com.
Sample: FFC-CKS11B110
FFC-
Code
3
4
C
L
Passband
Wavelength
1480±40
nm
1310±40
nm
1550±40
nm
1590±40
nm
Code
H
L
S
Housing
Ø 3.0 mm
cable
Ø 900 µm fiber
Ø 250 µm fiber
Code
1
2
Grade
Grade 1
Grade 2
B
Code
1
1
Fiber Type
Corning
SMF-28
Code
0
1
2
3
4
5
6
7
8
9
A
B
C
Connectors
NONE
FC/PC
FC/SPC
FC/APC
SC/SPC
SC/APC
BICONIC
D4
ST
FC/UPC
SC/UPC
LC
MU
Code
1
2
3
5
A
C
E
F
H
K
Coupling Ratio
1%
2%
3%
5%
10%
20%
30%
33%
40%
50%
Code
0
1
2
Configuration
1x1 (attenuator)
1x2
2x2
Code
B
Bandwidth
Broadband
Code
0
1
2
3
4
5
6
7
8
9
A
Pigtail Length
0.5 meter
1 meter
2 meters
3 meters
4 meters
5 meters
6 meters
7 meters
8 meters
9 meters
10 meters
SMF-28 is a registered trademark of Corning Incorporated.
LC and ST are registered trademarks of Lucent Technologies.
Telcordia is a registered trademark of Telcordia Technologies Incorporated.
NORTH AMERICA
:
800 498-JDSU (5378)
WORLDWIDE
:
+800 5378-JDSU
WEBSITE
:
www.jdsu.com
Product specifications and descriptions in this document subject to change without notice. © 2007 JDS Uniphase Corporation 10113913 Rev. 003 10/05 FFCSW.DS.CC.AE
March 2007
Test/Measurement
