Totalizers electromechanic
Impulse counters adding, imprint on card
Display 5- or 6-digits, manual reset by lever
FD270
Features
– Large pulse counter
– Adding
– Display 5- or 6-digits
– Imprint of the measured result on card, paper stripes
or labels
– Manual imprint, reset and ink ribbon transport by
reset lever
FD270 - Impulse counter
Technical data - electrical ratings
Voltage supply
115 VAC ±10 % (60 Hz)
230 VAC ±10 % (50 Hz)
24 VDC ±10 %
<48 %
50 / 60 Hz
≤600 mA
14 W, 20 VA
1:1
CE conform
Technical data - mechanical design
Display
Number of digits
Digit height
Count mode
Step-by-step switching
Measuring range
Reset
Imprint
Card thickness
Card width
Ink ribbon transport
Operating temperature
Storing temperature
Relative humidity
Protection DIN EN 60529
Housing type
E-connection
Mounting
Dimensions W x H x L
Weight approx.
Material
White numbers on black
5-digits
6-digits
7 mm (numeral readout)
3 mm (printed numerals)
1 impulse = 1 count
Adding in whole steps
99 999 and 999 999
Manual by reset lever
With lever, without reset
By lever upon reset
≤0.3 mm
85...0 mm
Manual by knurled knob
-20...+70 °C
80 % non-condensing
IP 41
Housing with ground plate
Cable gland PG 9
Surface mount housing
237 x 152 x 113.5 mm
3500 g
Aluminium die cast alloy
Subject to modification in technic and design. Errors and omissions excepted.
30/10/2008
Ripple residue
Nominal frequency
Current consumption
Power consumption
Pulse ratio
Approval
0...+60 °C
1
www.baumerivo.com
Impulse counters adding, imprint on card
Display 5- or 6-digits, manual reset by lever
Totalizers electromechanic
FD270
Part number
FD270.
Display
5-digits 9999.9
5-digits 99999
6-digits 999 999
6-digits 99999.5,
count mode 0-5-0-5
Connection diagram
-(+)
A5
A7
C1
B7
Voltage
+(-)
Encoder
Trigger level
Voltage
Power
Nominal current
Resistance
Voltage
Power
Nominal current
Resistance
Voltage
Power
Nominal current
Resistance
Dimensions
24 VDC ±10 %
14 W
600 mA
38
Ω
115 VAC ±10 %
20 VA
180 mA
50
Ω
230 VAC +6/-10 %
20 VA
80 mA
290
Ω
Voltage
1 24 VDC
5 115 VAC / 60 Hz
6 230 VAC / 50 Hz
010A
020C
Imprint / reset
Imprint and reset operation parallel
Imprint and reset operation separate
90°
117
237
92
150
2
www.baumerivo.com
30/10/2008
Subject to modification in technic and design. Errors and omissions excepted.
118.5
125
113.5
