BZT03D...
Vishay Telefunken
Silicon Z–Diodes and Transient Voltage Suppressors
Features
D
Glass passivated junction
D
Hermetically sealed package
D
Clamping time in picoseconds
Applications
Medium power voltage regulators and medium power
transient suppression circuits
94 9539
Order Instruction
Type
BZT03D6V2
Ordering Code
BZT03D6V2–TAP
BZT03D6V2–TR
Remarks
Ammopack
Tape and Reel
Absolute Maximum Ratings
T
j
= 25
_
C
Parameter
Power dissipation
Test Conditions
l=10 mm, T
L
=25
°
C
T
amb
=25
°
C
Type
Symbol
P
V
P
V
P
ZRM
P
ZSM
T
j
T
stg
Value
3.25
1.3
10
600
175
–65...+175
Unit
W
W
W
W
°
C
°
C
Repetitive peak reverse power dissipation
Non repetitive peak surge power dissipation t
p
=100
m
s, T
j
=25
°
C
Junction temperature
Storage temperature range
Maximum Thermal Resistance
T
j
= 25
_
C
Parameter
Junction ambient
Test Conditions
l=10 mm, T
L
=constant
on PC board with spacing 25 mm
Symbol
R
thJA
R
thJA
Value
46
100
Unit
K/W
K/W
Electrical Characteristics
T
j
= 25
_
C
Parameter
Forward voltage
Test Conditions
I
F
=0.5A
Type
Symbol
V
F
Min
Typ
Max
1.2
Unit
V
Document Number 85600
Rev. 3, 12-Mar-01
www.vishay.com
1 (4)
BZT03D...
Vishay Telefunken
Characteristics
(T
j
= 25
_
C unless otherwise specified)
50
3
I
F
– Forward Current ( A )
3.0
2.5
2.0
T
j
= 25°C
1.5
1.0
0.5
0
7
2
94 9086a
94 9585
25
50
0
0.5
1.0
1.5
2.0
V
F
– Forward Voltage ( V )
Figure 1. Epoxy glass hard tissue, board thickness
1.5 mm, R
thJA
100 K/W
x
Figure 3. Forward Current vs. Forward Voltage
4
P
tot
– Total Power Dissipation ( W )
l=10mm
3
15mm
2
20mm
1
see Fig.1
0
0
94 9584
P
ZSM
– Non-Repetitive Surge Power
Dissipation ( W )
l
l
10000
T
j
= 25°C
1000
T
L
=constant
100
40
80
120
160
200
94 9586
10
0.01
0.1
1
10
100
T
amb
– Ambient Temperature (
°C
)
t
p
– Pulse Length ( ms )
Figure 2. Total Power Dissipation vs.
Ambient Temperature
Figure 4. Non Repetitive Surge Power Dissipation vs.
Pulse Length
Dimensions in mm
∅
3.6 max.
Sintered Glass Case
SOD 57
Weight max. 0.5 g
Cathode Identification
technical drawings
according to DIN
specifications
94 9538
∅
0.82 max.
26 min.
4.2 max.
26 min.
Document Number 85600
Rev. 3, 12-Mar-01
www.vishay.com
3 (4)
BZT03D...
Vishay Telefunken
