SAW Components
Resonator
Data Sheet
R2712
804.50 MHz
SMD Ceramic package
QCC8C
Features
s
2-port resonator
s
nominal 180˚-phase at resonance
s
Provides reliable, fundamental mode, quartz fre-
quency stabilization i.e. in transmitters or local
oscillators
s
Passivation layer: Protec
Terminals
s
Ni, gold plated
Dimensions in mm, approx. weight 0,1 g
Pin configuration
2
6
7
3
4,8
Input / Ouptput
Output / Input
Ground (Input / Output)
Ground (Output / Input)
Ground (case)
Type
R2712
Ordering code
B39801-R2712-U310
Marking and Package
according to
C61157-A7-A56
Packing
according to
F61074-V8169-Z000
Electrostatic Sensitive Device
(ESD)
Maximum ratings
Operable temperature range
Storage temperature range
DC voltage
Source power
T
A
T
stg
V
DC
P
s
–45/+85
–45/+85
0
0
˚C
˚C
V
dBm
between any terminals
2
Oct 02, 2003
SAW Components
Resonator
Data Sheet
Characteristics
Reference temperature:
Terminating Source impedance:
Terminating Load impedance:
R2712
804.50 MHz
T
A
= 25 ˚C
Z
S
= 50
Ω
Z
L
= 50
Ω
min.
typ.
804.5
max.
804,75
MHz
Center frequency
(center frequency between 3 dB points)
Minimum insertion attenuation
Phase at f
c
Loaded quality factor
Unloaded quality factor
Ageing of f
c
Equivalent circuit elements
Motional capacitance
Motional inductance
Motional resistance
Input / Output capacitance
Temperature coefficient of frequency
1)
Turnover temperature
1)
Temperature
f
c
804,25
α
min
ϕ
Q
L
Q
U
—
—
3000
6300
—
6,3
140
3700
7500
—
0,293
133,8
91
1,6
–0,03
—
8,3
—
—
—
dB
˚ el.
−10/+40
ppm
—
—
—
—
—
35
fF
µH
Ω
pF
ppm/K
2
˚C
C
1
L
1
R
1
C
0
—
—
—
—
—
15
TC
f
T
0
dependence of
f
c
:
f
c
(T
A
) =
f
c
(T
0
)(1 +
TC
f
(T
A
–
T
0
)
2
)
3
Oct 02, 2003
SAW Components
Resonator
Data Sheet
R2712
804.50 MHz
