CD4614 thru CD4627
Zener Diode Chip Series
Rev. V2
Features
•
0.5 W Capability with Proper Heat Sinking
•
Electrically Equivalent to 1N4614
-
1N4627
Die
Description
These 0.5 W zener diodes are electrically equivalent
to the 1N4614
-
1N4627 series diodes. They are
compatible with all wire bonding and die attach
techniques with the exception of solder reflow.
These diodes are available in JANHC and JANKC
per MIL-PRF-19500/127.
Electrical Specifications: Zener Test Current = 250 µA, T
A
= +25°C
Zener Voltage
1
V
Z
@ 250 µA
Nominal
V
CD4614
CD4615
CD4616
CD4617
CD4618
CD4619
CD4620
CD4621
CD4622
CD4623
CD4624
CD4625
CD4626
CD4627
1.8
2.0
2.2
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
Zener Impedance
2
Z
ZT
@ 500 µA
Maximum
Ω
1200
1250
1300
1400
1500
1600
1650
1700
1650
1600
1550
1500
1400
1200
µA
7.5
5.0
4.0
2.0
1.0
0.8
7.5
7.5
5.0
4.0
10.0
10.0
10.0
10.0
Reverse Voltage
I
R
@ V
R
Maximum
V
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.0
2.0
2.0
3.0
3.0
4.0
5.0
Part #
1. Zener voltage range equals nominal voltage ±5% for “A” suffix. No suffix denotes ±10%, “C” suffix = ±2% and “D” suffix = ±1%.
2. Zener impedance is derived by superimposing on I
ZT
at 60 HZ RMS AC current equal to 10% of I
ZT
.
1
* Restrictions on Hazardous Substances, European Union Directive 2011/65/EU.
VPT Components and its affiliates reserve the right to make changes to the product(s) or information contained herein without notice.
Visit
www.vptcomponents.com
for additional data sheets and product information.
For further information and support please visit:
www.vptcomponents.com
CD4614 thru CD4627
Zener Diode Chip Series
Rev. V2
Absolute Maximum Ratings
3,4
Forward Voltage
Operating Temperature
Storage Temperature
1.5 V @ 200 mA
-65°C
to +175°C
-65°C
to +175°C
Zener Impedance vs. Operating Current
3. Exceeding any one or combination of these limits may cause
permanent damage to this device.
4. VPT Components does not recommend sustained operation
near these survivability limits.
Die
Top: (anode) AL
Back: (cathode) Au
AL Thickness:
25,000 Å Minimum
Gold Thickness:
4,000 Å Minimum
Chip Thickness:
10 mils
Circuit Layout Data: For Zener operation, cathode must be
operated positive with respect to anode.
