SMV1404-09: DescriptionVariable Capacitance Diode, Very High Frequency, 120pF C(T), 12V, Silicon, Hyperabrupt, PLASTIC PACKAGE-3; CategoryDiscrete semiconductor diode; File Size37KB，1 Pages; ManufacturerCobham PLC

Download Datasheet Parametric View All

SMV1404-09 Overview

Variable Capacitance Diode, Very High Frequency, 120pF C(T), 12V, Silicon, Hyperabrupt, PLASTIC PACKAGE-3

SMV1404-09 Parametric

Parameter Name	Attribute value
Maker	Cobham PLC
package instruction	PLASTIC PACKAGE-3
Reach Compliance Code	unknown
ECCN code	EAR99
Minimum breakdown voltage	12 V
Configuration	COMMON ANODE, 2 ELEMENTS
Diode Capacitance Tolerance	20%
Minimum diode capacitance ratio	10
Nominal diode capacitance	120 pF
Diode component materials	SILICON
Diode type	VARIABLE CAPACITANCE DIODE
frequency band	VERY HIGH FREQUENCY
JESD-30 code	R-PDSO-G3
Number of components	2
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Maximum power dissipation	0.25 W
Certification status	Not Qualified
minimum quality factor	200
Maximum repetitive peak reverse voltage	12 V
surface mount	YES
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Varactor Diode Classification	HYPERABRUPT
Base Number Matches	1

Preview

Download Datasheet

View All

SILICON HYPERABRUPT

TUNING DIODES

•

High capacitance ratios

•

Linear tuning between 2 and 8 volts

•

Available over a broad range junction capacitances

•

Satisfies a large number of broadband applications thru the VHF frequency band

SMV1401 - SMV1412

DIODE CAPACITANCE

TUNING RATIO (TR)

(CT)

C•1V / C•10V C•2V / C•10V

•

pF @ 1V•1MHz pF @ 2V•1 MHz

•

@ 1 MHz

MIN

MAX MIN

MAX

MIN

440

660

14:1

45

69

10:1

140

210

10:1

96

144

10:1

200

300

10:1

80

120

10:1

54

82

10:1

37

57

10:1

26

40

10:1

17

27

9.5:1

12

18

8.5:1

8

12

7.5:1

QUALITY FACTOR

AVAILABLE

Q

IN THE FOLLOWING

@ 2V • 1 MHz

PACKAGES

MIN

200

-01, -14, -15

200

-01, -08, -09, -15

200

-01, -09, -15

200

-01, -08, -09, -15

200

-01, -09, -15

200

-01, -08, -09, -15

200

-01, -08, -09, -15

200

-01, -06, -08, -09, -10, -15

200

-01, -08, -06

200

-01, -06, -07, -08, -09, -10, -15

200

-01, -06, -07, -08, -09, -10, -15

200

-01, -06, -07, -08, -09, -10, -15

PART

NUMBER

♦♦♦

SMV1401

SMV1402

SMV1403

SMV1404

SMV1405

SMV1406

SMV1407

SMV1408

SMV1409

SMV1410

SMV1411

SMV1412

Device Dissipation (P

D

)

Ta = 25°C

Junction Temperature (T

J

)

Reverse Breakdown Voltage (V

BR

) 10 µAdc

Max Reverse Leakage Current (I

R

) Vr = 10 Vdc

Operating Temperature (Topr)

Storage Temperature (Tstg)

Capacitance Tolerance

♦♦♦

250 mW

125°C

12 Vdc Min

0.1 µAdc

-55° to + 125°C

-65° to + 150°C

Standard Device ± 20%

Package Styles

Requires adding a dash suffix number to the part number

SOT23 SINGLE

SOT23 Common Anode

SOT23 Common Cathode

SOT223

SOD323

SOD523 (SC79, SC90)

TO92 2 Terminal (TMV)

CHIPS

-08

-09

-10

-14

-06

-07

-15

-01

P.O. BOX 609

•

ROCKPORT, MAINE 04856

•

207-236-6076

•

FAX 207-236-9558
