EA_S-1W & FB_S-1W Series
1W, FIXED INPUT, 5200V ISOLATED & UNREGULATED
DUAL/SINGLE OUTPUT DC-DC CONVERTER
multi-country patent protection
RoHS
FEATURES
5.2KVDC Isolation
SIP Package
Temperature Range: -40°C to +85°C
No Heat Sink Required
Internal SMD Construction
Low Isolation Capacitance
No External Component Required
Industry Standard Pinout
RoHS Compliance
PRODUCT PROGRAM
Part
Number
EA0505S-1W
EA0509S-1W
EA0512S-1W
EA0515S-1W
FB0505S-1W
FB0509S-1W
FB0512S-1W
FB0515S-1W
EA1205S-1W
5
4.5-5.5
Input
Voltage (VDC)
Nominal
Range
Voltage
(VDC)
±5
±9
±12
±15
5
9
12
15
±5
±9
±12
12
10.8-13.2
±15
5
9
12
15
±5
±9
±12
24
21.6-26.4
±15
5
9
12
15
Output
Current (mA)
Max
±100
±56
±42
±33
200
111
83
67
±100
±56
±42
±33
200
111
83
67
±100
+56
±42
±33
200
111
83
67
Min
±10
±6
±5
±4
20
12
9
7
±10
±6
±5
±4
20
12
9
7
±10
±6
±5
±4
20
12
9
7
70
71
72
74
70
71
72
74
70
72
74
75
70
72
74
75
72
74
76
78
72
74
76
78
Efficiency
(%, Typ)
APPLICATIONS
The EA_S-1W
& FB_S-1W
Series
are
specially designed for applications where a
group of polar power supplies are isolated from
the input power supply in a distributed power
supply system on a circuit board.
These products apply to:
1) Where the voltage of the input power supply
is fixed (voltage variation
≤ ±10%);
2) Where isolation is necessary between input
and output (isolation voltage
≤5200VDC);
3) Where the regulation of the output voltage
and
the
output
ripple
noise
are
not
demanding.
Such as: purely digital circuits, ordinary low
frequency analog circuits, and IGBT power
device driving circuits.
EA1209S-1W
EA1212S-1W
EA1215S-1W
FB1205S-1W
FB1209S-1W
FB1212S-1W
FB1215S-1W
EA2405S-1W
EA2409S-1W
EA2412S-1W
EA2415S-1W
FB2405S-1W
FB2409S-1W
FB2412S-1W
FB2415S-1W
ISOLATION SPECIFICATIONS
Item
Isolation voltage
Isolation resistance
Test Conditions
Tested for 1 minute and 1mA max
Test at 1000VDC
Min
5200
1000
10
Typ
Max
Units
VDC
MΩ
pF
MODEL SELECTION
Isolation capacitance
EA0505S-1W
Rat ed Power
Pa ck a g e St yle
O u t p u t Vo lt a g e
In p u t Volta g e
Pro du c t S e rie s
COMMON SPECIFICATIONS
Item
Storage humidity
Operating temperature
Storage temperature
Lead temperature
Temp. rise at full load
Short circuit protection*
5V input voltage
12V/24V input voltage
1.5mm from case for 10 seconds
15
-40
-55
Test Conditions
Min
Typ
Max
95
85
125
300
25
1
Continuous
Free air convection
Plastic(UL94-V0)
3500
4.2
K hours
g
Second
°C
Units
%
MORNSUN Science & Technology co., Ltd.
Address:
2th floor 6th building, Hangzhou
Industrial District, Guangzhou, China
Tel: 86-20-38601850
Fax: 86-20-38601272
http://www.mornsun-power.com
Cooling
Case material
MTBF
Weight
*supply voltage must be discontinued at the end of short circuit duration.
MORNSUN reserves the copyright
Specifications subject to change without notice.
EA_S-1W & FB_S-1W
A/1-2008
Page 1 of 2
OUTPUT SPECIFICATIONS
Item
Output power
Line regulation
Test conditions
Min
0.1
Max
Units
1
W
±1.2
12.8
15
%
8.3
15
6.8
15
6.3
15
See tolerance envelope graph
0.03
%/°C
150
200
mVp-p
250
KHz
42
Typ
Recommended testing and application circuit
If you want to further decrease the input/output
ripple,
an
“LC”
filtering
network
may
be
connected to the input and output ends of the
DC/DC converter, see (Figure 1).
Dual Output
L
For Vin change of 1%
10% to 100% load(5V output)
10% to 100% load (9V output)
Load regulation
10% to 100% load (12V output)
10% to 100% load (15V output)
Output voltage accuracy
Temperature drift
100% full load
Ripple & Noise*
20MHz Bandwidth
(5V input)
Full load,
Switching frequency
nominal input
(others input)
L
Vin
Cin
+Vo
Cout
DC DC
GND
Single Output
L
L Cout
0V
-Vo
L
Vin
Cin
+Vo
Cout
*Test ripple and noise by
“parallel
cable” method. See detailed operation instructions at Testing of Power
Converter section, application notes.
Note:
1. All specifications measured at TA=25°C, humidity<75%, nominal input voltage and rated output load
unless otherwise specified.
2. Dual output models unbalanced load:
±5%.
DC DC
(Figure 1)
GND
0V
It should also be noted that the inductance and
the frequency of the
“LC”
filtering network should
be staggered with the DC/DC frequency to avoid
mutual interference. However, the capacitance of
the output filter capacitor must be proper. If the
capacitance is too big, a startup problem might
arise. For every channel of output, provided the
safe and reliable operation is ensured, the
greatest capacitance of its filter capacitor sees
(Table 1).
EXTERNAL CAPACITOR TABLE (TABLE 1)
TYPICAL CHARACTERISTICS
Ambient Temperature
( C )
Vin
(VDC)
5
12
24
-
Cin
(uF)
4.7
2.2
1
-
OUTLINE DIMENSIONS & PIN CONNECTIONS
First A ngle Projection
RECOMMENDED FOOTPRINT
Top
view,grid:2.54mm(0.1inch)
diameter:1.00mm(0.039inch)
1 2
5 6
Single Cout
Vout (uF)
(VDC)
5
10
9
4.7
12
2.2
15
1
Dual
Vout
(VDC)
±5
±9
±12
±15
Cout
(uF)
4.7
2.2
1
1
It’s not recommended to connect any external
capacitor in the application field with less than 0.5
watt output.
Dual Output
1
2
5 6
7
Output Voltage Regulation and Over-voltage
Protection Circuit
The simplest device for output voltage
regulation,
over-voltage
and
over-current
protection is a linear voltage regulator with
overheat protection that is connected to the input
Single Output
1
2
5
7
or output end in series (Figure 2).
Dual Output
FOOTPRINT DETAILS
Pin
Note:
Unit:mm(inch)
Pin section: 0. 50*0.30mm(0.020*0.012inch)
Pin tolerances: 0.10mm( 0.004inch)
General tolerances: 0.25mm( 0.010inch)
1
2
5
6
7
Singles
Duals
Vin
GND
REG
REG
+Vout
0V
DC DC
REG
-Vout
+Vout
Single Output
Vin
GND
REG
REG
DC DC
0V
APPLICATION NOTE
Requirement on output load
To ensure this module can operate efficiently and reliably, During operation, the minimum
output load is
not less than 10%
of the full load, and that
this product should never be
operated under no load!
If the actual output power is very small, please connect a resistor
with proper resistance at the output end in parallel to increase the load, or use our company’s
products with a lower rated output power.
(Figure 2)
Overload Protection
Under normal operating conditions, the output
circuit of these products has no protection
against overload. The simplest method is to
connect a self-recovery fuse in series at the input
end or add a circuit breaker to the circuit.
No parallel connection or plug and play.
MORNSUN reserves the copyright
Specifications subject to change without notice.
EA_S-1W & FB_S-1W
A/1-2008
Page 2 of 2
