Pin Strip |
Spacing 5.08 mm
STLZ950/..G-5.08-H-GREEN
Technical Data
Wire sizes
Solid min
Solid max
Stranded (flexible) min
Stranded (flexible) max
Stranded with Ferrule min
Stranded with Ferrule max
-
-
-
-
-
-
Order Data (Spacing 5.08 mm)
Insulating Material
Material
Flammability Class
PA 6.6
2
11.36
16.44
21.52
26.60
31.68
36.76
41.84
46.92
52.00
57.08
62.16
67.24
72.32
77.40
82.48
87.56
92.64
97.72
102.80
107.88
112.96
118.04
123.12
STLZ950/2G-5.08-H-GREEN
STLZ950/3G-5.08-H-GREEN
STLZ950/4G-5.08-H-GREEN
STLZ950/5G-5.08-H-GREEN
STLZ950/6G-5.08-H-GREEN
STLZ950/7G-5.08-H-GREEN
STLZ950/8G-5.08-H-GREEN
STLZ950/9G-5.08-H-GREEN
STLZ950/10G-5.08-H-GREEN
STLZ950/11G-5.08-H-GREEN
STLZ950/12G-5.08-H-GREEN
STLZ950/13G-5.08-H-GREEN
STLZ950/14G-5.08-H-GREEN
STLZ950/15G-5.08-H-GREEN
STLZ950/16G-5.08-H-GREEN
STLZ950/17G-5.08-H-GREEN
STLZ950/18G-5.08-H-GREEN
STLZ950/19G-5.08-H-GREEN
STLZ950/20G-5.08-H-GREEN
STLZ950/21G-5.08-H-GREEN
STLZ950/22G-5.08-H-GREEN
STLZ950/23G-5.08-H-GREEN
STLZ950/24G-5.08-H-GREEN
Poles
Width (mm)
Article Designation
Article
Number
50950025021 F
50950035021 F
50950045021 F
50950055021 E
50950065021 E
50950075021 E
50950085021 D
50950095021 D
50950105021 D
50950115021 D
50950125021 D
50950135021 D
50950145021 D
50950155021 D
50950165021 D
50950175021 D
50950185021 D
50950195021 D
50950205021 D
50950215021 D
50950225021 D
50950235021 D
50950245021 D
PU
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
UL 94 V-0
3
4
Temperatures
Operating Temperature
(without mech. load)
Store Temperature
-40 °C - 105 °C
-40 °C - 105 °C
5
6
7
Dimensions
PCB Hole Diameter
1.4 mm
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
260 °C
3-4 s
8
9
10
11
12
Materials
Contact Pin
Copper
Alloy
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
-
-
13
14
15
16
17
18
Colours
GREEN, RAL 6018
BLACK, RAL 9011
BASALT GREY, RAL 7012
PEBBLE GREY, RAL 7032
LIGHT GREY, RAL 7035
LIGHT GREEN, similar RAL 6018
Colours according to RAL, there may be variations on colour due to production conditions. Special
colours on request.
19
20
21
22
23
24
Accessoires
Figure
Designation
Coding Star CS2-5.0/5.08-RED
Article Number
Order Data: 50000000024
Counterparts (Spacing 5.08 mm)
Pin Strip/Terminal Block
STLZ950-INV
AKZ950
AKZ955
AKZ1100
AKZ1110
AKZ1200
AKZ4951
In combination of connectors with different admission data, the lower value is valid.
Separating Element
SE-STL950-GREEN
Order Data: 50950000002
Ratings
UseGroup
Rated Voltage
Rated Current
Overvoltage Category
Test Voltage
Pollution Degree
B
300 V
15 A
C
150 V
15 A
D
300 V
10 A
250 V
12 A
III
1.60 kV
1.30 kV
1.60 kV
4.0 kV
3
PTR HARTMANN GmbH
• Gewerbehof 38 • 59368 Werne / Germany
Telefon: +49 (0)2389/7988-0 •
E-Mail: info@ptr-hartmann.com
www.ptr.eu
