mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
wire termination
on straight side
314
Additional Centerline
Type 314
Type 49
Voltage
49
300 V - centerline 5 mm
600 V - centerline 10 mm
12 A
12 - 28 AWG
4.5 lbs. - in
8 mm
≤
10 mΩ per circuit
Voltage
with
rising clamp system
Electrical Data
Electrical Data
300 V - centerline 5 mm
600 V - centerline 10 mm
15 A
12 - 22 AWG
#### (see note)
8 lbs. - in
6 mm
≤
5 mΩ per circuit
.54 - 1.0 lbs.
.17 - .79 lbs.
Headers that mate with
Type 314
Type 319
Type 320
Type 329
Type 330
Type 270
Type 274
Type 276
Type 278
Type 280
Type 49
Type 19
Type 29
Type 20
Type 33
Type 30
Type 34
Page H-14
Page H-18
Page H-15
Page H-16
Page H-19
Page H-20
Page H-15
Page H-17
Page H-19
Page H-21
Page H-22
Page H-22
Page H-24
Page H-23
Page H-24
Current
Wire range
Screw torque
Wire strip length
Contact resistance
Current
Wire range
Screw torque
Wire strip length
Contact resistance
Insertion force
Withdrawal force
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, nickel plated
copper alloy, tin plated
M3, steel,
nickel over copper plating
2 to 24 - centerline 5 mm
2 to 12 - centerline 10 mm
Mechanical Data
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
Color
brown
Terminal
brass, nickel plated
Contact socket
berylliumcopper,
silver over nickel plating
optional: tin/gold plating
- consult factory
Wire protector
German silver
Screw
M3, steel,
nickel over copper plating
Pole sizes
2 to 24 - centerline 5 mm
2 to 12 - centerline 10 mm
Additional material data - pages DA-3 to DA-5
Housing
Color
Terminal
Wire protector
Screw
Pole sizes
Additional material data - pages DA-3 to DA-5
Accessories
for
Type 49
Coding set
716906
Page J-9
Dimensions (mm)
Dimensions (mm)
Latches
716769/716770Page J-6
Latches used with header
Type 33
or
Type 34
Page H-16
Page H-20
L = (circuits - 1) x centerline + 5
L = (circuits - 1) x centerline + 5
Coding set
720254-01-6
720254-02-5 Page J-10
Part Numbers
Type 314
Complete the part number
by adding the pole size.
centerline 5 mm
Part Numbers
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
Type 49
Complete the part number
by adding the pole size.
centerline 5 mm
Part No.
313141
Type 314
centerline 10 mm
Part No.
310491
Type 49
centerline 10 mm
02 03 04 05 06 07 08
09 10 11 12 13 14 15 16
17 18 19 20 21 22 23 24
02 03 04 05 06 07 08
09 10 11 12
Type 49
#### 2 No. 22-18 AWG
(Field-wiring);
2 No. 26-18 AWG or
1 No. 26-14 AWG
(Factory-wiring)
Part No.
313142
Part No.
310492
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DB-11
