N Fixed Coaxial Attenuators
3082 Series
Description
Type N series attenuators have been designed for use
where stable, broadband, medium power units are
required. Any combination of precision stainless steel
Type N plug and jack connectors is available on these
units. Contact the factory for part numbers and specifica-
tions. Standard configuration is one Type N plug and
one Type N jack.
Outline
Power:
Finish:
2 Watts Average
Passivated Stainless Steel
500
Watts Peak
Weight:
See Derating Curve
on Page 4 2.5 oz. (70.9g)
PART NUMBER
PLUG-JACK
3082-6191-03
3082-6192-06
3082-6193-10
3082-6194-20
3082-6195-30
3082-6141-03
3082-6142-06
3082-6143-10
3082-6144-20
3082-6145-30
3082-6181-03
3082-6182-06
3082-6183-10
3082-6184-20
3082-6185-30
3082-6171-03
3082-6172-06
3082-6173-10
3082-6174-20
3082-6175-30
FREQUENCY
(GHz)
DC
- 18.0
DC
- 18.0
DC
- 12.4
DC
- 4
ATTENUATION
(dB)
3.0 ± 0.30
6.0 ± 0.30
10.0 ± 0.50
20.0 ± 0.75
30.0 ± 1.00
3.0
± 0.60
6.0
± 0.75
10.0
±
1.25
20.0
±
1.50
30.0 ±
2.00
3.0 ± 0.30
6.0 ± 0.30
10.0 ± 0.50
20.0 ± 0.75
30.0 ± 1.00
3.0 ± 0.30
6.0 ± 0.30
10.0 ± 0.50
20.0 ± 0.75
30.0 ± 1.00
VSWR
DC
to 4 GHz 1.15
4 to 12.4 GHz 1.25
12.4 to 18 GHz 1.35
DC
to 4 GHz 1.20
4 to 12.4 GHz 1.40
12.4 to 18 GHz 1.60
DC
to 4 GHz 1.15
4 to 12.4 GHz 1.25
DC
to 4 GHz 1.15
Non-standard versions available.
Contact franchised distributor or factory.
Phone: 603-222-2256
fax: 603-222-2259
www.XMAcorp.com
