February 26, 2007
SELF-LEADED SMD INDUCTOR DR339-4 SERIES
Features
Surface Mount Design
Inductance Range from 0.47µH to 100µH
Operating Temp. -40°C to +85°C
Tinned Leads with Leaded Solder is Available
(note 5)
ELECTRICAL SPECIFICATIONS AT 25°C
Part No.
DR339-4-471
DR339-4-102
DR339-4-152
DR339-4-222
DR339-4-332
DR339-4-472
DR339-4-682
DR339-4-103
DR339-4-153
DR339-4-223
DR339-4-333
DR339-4-473
DR339-4-683
DR339-4-104
Inductance (µH)
0.47 +40/-20%
1.0 +40/-20%
1.5 +40/-20%
2.2
±20%
3.3
±20%
4.7
±20%
6.8
±20%
10
±20%
15
±20%
22
±20%
33
±20%
47
±20%
68
±20%
100
±20%
DCR
(Ω) Max.
0.002
0.003
0.004
0.005
0.006
0.010
0.015
0.020
0.030
0.040
0.060
0.074
0.120
0.170
I rms (A)
Max. (Note 3)
19.2
17.3
13.4
12.0
11.0
8.6
8.3
6.8
5.5
4.5
3.7
3.1
2.4
2.0
I sat (A)
Max. (Note 2)
51.7
37.8
28.9
23.7
20.2
15.6
14.1
11.5
9.1
7.6
6.1
5.2
4.3
3.6
MECHANICAL OUTLINES
.574
14,60
.590 MAX.
1
15,00
339-4
XXX
1
2
2
SCHEMATIC
.307 MAX.
7,80
.169
4,30
.531
13,50
.874 MAX.
22,20
SUGGESTED PAD LAYOUT
.393
10,00
Notes:
1. All dimensions are shown in inches/millimeter “mm”
Unless otherwise specified, tolerance = Inches: ± 0.010
= Millemeters: ± 0,30
2. Isat based on the inductance being 70% of it initial value
3. I
rms
based on 40°C temperature rise
4. Tape and reel quantity, 250 pcs/reel
5. For non-RoHS parts replace DR prefix with 42- (e.g. DR339-4 becomes 42-339-4)
6. Terminal finish is compliant to RoHS requirements. Solder in accordance with J-STD-020C
DATATRONIC:
28151 Highway 74, Romoland, CA 92585 Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice.
