DR217-5 SERIES RADIAL LEADED INDUCTORS
Features
Designed for EMI Filters & Switching Power Supplies
Inductance Range from 3.3µH to 100mH
Operating Temp. -20°C to +80°C
Tinned Leads with Leaded Solder is Available
(note 4)
ELECTRICAL SPECIFICATIONS AT 25ºC
Part Number
Inductance
(µH) @1kHz
3.3 ± 20%
3.9 ± 10%
4.7 ± 10%
5.6 ± 10%
6.8 ± 10%
8.2 ± 10%
10 ± 10%
12 ± 10%
15 ± 10%
18 ± 10%
22 ± 10%
27 ± 10%
33 ± 10%
39 ± 10%
47 ± 10%
56 ± 10%
68 ± 10%
82 ± 10%
100 ± 10%
120 ± 10%
150 ± 10%
180 ± 10%
220 ± 10%
270 ± 10%
330 ± 10%
390 ± 10%
470 ± 10%
560 ± 10%
680 ± 10%
820 ± 10%
1000 ± 10%
1200 ± 10%
1500 ± 10%
Q Min.
Q Test Freq.
SRF
(MHz)
TYP.
65
55
45
38
27
21
17
15
13
12
11
10
8.5
7.7
6.7
6.4
5.8
5.2
4.4
4.2
3.7
3.5
3.3
2.9
2.6
2.4
2.2
2.0
1.8
1.7
1.5
1.4
1.3
DCR
(Ohm)
Max.
0.012
0.014
0.016
0.02
0.022
0.024
0.025
0.027
0.033
0.039
0.047
0.052
0.075
0.082
0.1
0.15
0.18
0.2
0.2
0.22
0.24
0.28
0.35
0.4
0.47
0.68
0.8
1
1.2
1.5
1.8
2
2.4
Rated DC
Current (A) Max.
5.0
4.6
4.3
3.9
3.7
3.5
3.2
3.0
2.8
2.6
2.4
2.1
1.9
1.7
1.5
1.3
1.2
1.1
0.9
0.8
0.72
0.65
0.60
0.55
0.50
0.46
0.42
0.38
0.35
0.31
0.28
0.25
0.23
DR217-5-332
DR217-5-392
DR217-5-472
DR217-5-562
DR217-5-682
DR217-5-822
DR217-5-103
DR217-5-123
DR217-5-153
DR217-5-183
DR217-5-223
DR217-5-273
DR217-5-333
DR217-5-393
DR217-5-473
DR217-5-563
DR217-5-683
DR217-5-823
DR217-5-104
DR217-5-124
DR217-5-154
DR217-5-184
DR217-5-224
DR217-5-274
DR217-5-334
DR217-5-394
DR217-5-474
DR217-5-564
DR217-5-684
DR217-5-824
DR217-5-105
DR217-5-125
DR217-5-155
30
30
30
30
30
30
50
50
50
50
50
50
50
40
40
40
30
30
30
30
30
30
20
20
20
20
20
20
20
20
40
40
40
7.96MHz
7.96MHz
7.96MHz
7.96MHz
7.96MHz
7.96MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
2.52MHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
796kHz
252kHz
252kHz
252kHz
DATATRONIC:
28151 Highway 74, Romoland, CA 92585 Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice. Page 1 of 2
October 11, 2006
DR217-5 SERIES RADIAL LEADED INDUCTORS
Part Number
Inductance
(uH) @1kHz
1800 ± 10%
2200 ± 10%
2700 ± 10%
3300 ± 10%
3900 ± 10%
4700 ± 10%
5600 ± 10%
6800 ± 10%
8200 ± 10%
10000 ± 10%
47000 ± 10%
100000 ± 10%
Q Min.
Q Test Freq.
SRF
(MHz)
TYP.
1.1
1.0
0.88
0.78
0.72
0.65
0.58
0.55
0.5
0.42
0.20
0.14
DCR
(Ohm)
Max.
2.8
3.3
5
5.6
6.2
7
9.1
10
15
24
80
180
Rated DC
Current (A) Max.
0.21
0.19
0.17
0.15
0.14
0.13
0.12
0.11
0.10
0.09
0.04
0.028
DR217-5-185
DR217-5-225
DR217-5-275
DR217-5-335
DR217-5-395
DR217-5-475
DR217-5-565
DR217-5-685
DR217-5-825
DR217-5-106
DR217-5-476
DR217-5-107
40
40
40
40
40
40
40
40
20
20
60
20
252kHz
252kHz
252kHz
252kHz
252kHz
252kHz
252kHz
252kHz
252kHz
79.6kHz
79.6kHz
79.6kHz
MECHANICAL SPECIFICATIONS
.039 MIN.
1,00
1
XXX
.196 ±.039
5,00 ±1,00
Ø .354 MAX.
9,00
1
2
.511 MAX.
13,00
.590 MIN.
15,00
2
Ø .025
TYP
0,65
SCHEMATIC
NOTES:
1. Dimensions are shown in inches/millimeters
2. Unless otherwise specified, tolerance = Inches: ±0.012
= Millimeters: ±0,30
3. IDC MAX based on the inductance being 90% of its initial value
4. For non-RoHS parts replace DR prefix with 42- (e.g. DR217-5 becomes 42-217-5)
5. Terminal finish is compliant to RoHS requirements
DATATRONIC:
28151 Highway 74, Romoland, CA 92585 Tel: 951-928-7700 Toll Free Tel: 888-889-5391 Fax: 951-928-7701
Email: ddisales@datatronics.com
499 King’s Road, Hong KongTel: (852) 2562 3858, (852) 2564 8477 Fax: (852) 2565 7214, (852) 2563 1290
All specifications are subject to change without notice.
Page 2 of 2
