mm to inch
1
.039
1.2
.047
1.3
.051
1.5
.059
2.5
.098
3.1
.122
3.2
.126
3.4
.134
3.5
.138
mm to inch
4.1
.161
5
.197
5.75 .244
8
.315
9.8
.386
10
.394
11.5
.453
13.5
.532
15
.591
Designed to VDE 0110
Designed to VDE 0110
141
Types are also available with
centerline 10 mm
Voltage
Type
with wire protection
161
300 V - 5.0 mm
600 V - 10.0 mm
15 A
14 - 22 AWG,
#, + (see note)
7 lbs. - in
1.0 mm
1.3 mm
8 mm
UL 94V-0
-40° F to 257° F
(-40° C to 125° C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M3, steel,
chromate over zinc plating
optional: stainless steel
- consult factory
centerline 5 mm: 2 - 24
centerline 10 mm: 2 - 12
Voltage
Type
with wire protection
staggered pins
Electrical/Mechanical Data
Electrical/Mechanical Data
300 V - 5.0 mm
600 V - 10.0 mm
20 A
12 - 22 AWG
7 lbs. - in
1.2 mm
1.5 mm
8 mm
UL 94V-0
-40° F to 257° F
(-40° C to 125° C)
brown
brass, tin over nickel plating
tin bronze, tin plated
M3, steel,
nickel over copper plating
optional: stainless steel
- consult factory
centerline 5 mm: 2 - 24
centerline 10 mm: 2 - 12
Current
Wire range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
Housing
Current
Wire range
Screw torque
Pin diameter
PCB hole diameter
Wire strip length
Housing
Color
Terminal
Wire protector
Screw
Color
Terminal
Wire protector
Screw
Pole size
Pole size
Additional material data - pages 27 to 29
Additional material data - pages 27 to 29
L = (circuits - 1) x centerline + 5
L = (circuits - 1) x centerline + 5
Part Numbers "Standard Style"
centerline 5 mm
circuits
Type 141
2
311411 02
4
311411 03
10
311411 04
centerline 10 mm
circuits
Type 141
Part Numbers "Standard Style"
centerline 5 mm
circuits
Type 161
3
311611 03
4
311611 04
5
311611 05
6
311611 06
centerline 10 mm
circuits
Type 161
Note for Wire range
Type 141
Additional wire sizes and/or combi-
nations of same size wires as follows:
#
1 No. 30 AWG
(Factory-wiring)
+
2 No. 22-16 AWG
(Field-wiring);
2 No. 30-16 AWG
(Factory-wiring)
Other Circuits please consult factory
A minimum of 3000 Circuits required
37
Other Circuits please consult factory
A minimum of 3000 Circuits required
