mm to inch
1 inch = 25.4 mm
1 mm = .040 inches
Designed to IEC 60664-1
Designed to IEC 60664-1
Type
Type
with lift system
modular
12
Non Modular Type
similar to
Type 12
Type 11
similar to
Type 72
Type 71
Page DA-16
Page DA-16
72
300 V
15 A
12 - 22 AWG
# (see note)
8 lbs. - in
.8 mm x 1 mm
1.4 mm
7 mm
with lift system
modular
Electrical Data
Voltage
Current
Wire Range
Screw torque
Square pin
PCB hole diameter
Wire strip length
Electrical Data
Voltage
Current
Wire Range
Screw torque
Square pin
PCB hole diameter
Wire strip length
300 V
20 A
12 - 22 AWG
## (see note)
6 lbs. - in
.8 mm x 1 mm
1.4 mm
8 mm
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, nickel plated
brass, tin over nickel plating
M3, steel
nickel over copper plating
2 to 4
Mechanical Data
Housing
UL 94V-0
-40 °F to 189 °F
(-40 °C to 105 °C)
brown
brass, nickel plated
brass, tin over nickel plating
M3, steel
nickel over copper plating
optional: stainless steel
- consult factory
2 to 4
Color
Terminal
Lift system
Screw
Pole sizes
Color
Terminal
Lift system
Screw
Pole sizes
Additional material data - pages DA-3 to DA-5
Additional material data - pages DA-3 to DA-5
Dimensions (mm)
Dimensions (mm)
Note for wire range
Additional wire sizes and/or
combinations of same size
wires as follows:
L = (circuits - 1) x centerline + 5
L = (circuits - 1) x centerline + 5
Part Numbers
Type 12
Complete the part number
by adding the pole size.
centerline 5 mm
Part Numbers
02 03 04
Type 12
#
1 No. 30 AWG
(Factory-wiring)
2 No. 22-16 AWG
(Field-wiring);
2 No. 30-16 AWG or
1 No. 30-12 AWG
(Factory-wiring)
Part No.
310121
Type 72
Complete the part number
by adding the pole size.
centerline 5 mm
02 03 04
Part No.
310721
Type 72
##
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
01 standard
08 Available on demand. Minimum order
quantity 3000 poles per item.
Subject to technical changes and printing errors.
RIA electronic, Inc.
430 Industrial Way West, Eatontown, NJ 07724
phone 1-888-722-5625
•
fax 732-389-9066
•
www.riaelectronic.com
DA-19
