ISD-A-13-S-B-2: DescriptionIsolator, FC/APC Connector; CategoryWireless rf/communication Optical fiber; File Size217KB，1 Pages; ManufacturerLightel Technologies Inc.

Download Datasheet Parametric View All

ISD-A-13-S-B-2 Overview

Isolator, FC/APC Connector

ISD-A-13-S-B-2 Parametric

Parameter Name	Attribute value
Maker	Lightel Technologies Inc.
Reach Compliance Code	unknown
Connection Type	FC/APC CONNECTOR
Fiber optic equipment types	ISOLATOR
Fiber type	SMF-28
Maximum insertion loss	0.9 dB
Minimum isolation	33 dB
Maximum operating temperature	70 °C
Minimum operating temperature
Nominal operating wavelength	1310 nm
Maximum optical input power	500 mW
minimum return loss	55 dB
Base Number Matches	1

Preview

Download Datasheet

View All

Isolator

Polarization Insensitive Dual Stage Isolator

Parameter

Central Wavelength (λc)

Bandwidth

Peak Isolation

Isolation in Band (+10nm, at 23° C)

Isolation in Band (0-70° C)

Insertion Loss in Band (0-70° C)

Return Loss (Input/Output)

PDL (λc, 23° C)

PMD

Maximum Power

Operating Temperature

Storage Temperature

Package Dimensions

Note1: All values specified are without connectors.

Note2: Higher performance specifications upon request.

Note3: Fiber type Corning SMF-28e.

Premium

± 20nm

56 dB

≥ 46 dB

≥ 35 dB

≤ 0.6 dB

≥ 60/55 dB

≤ 0.1 dB

≤ 0.1 ps

500 mW

0° C ~ + 70° C

A Grade

1310 nm, 1480 nm or 1550 nm

53 dB

≥ 45 dB

≥ 33 dB

≤ 0.9 dB

≥ 60/55 dB

- 40° C ~ + 85° C

5.5 mm () x 35 mm (L)

I S D -

Grade

P: Premium

A: A Grade

-

Center Wavelength

13: 1310 nm

14: 1480 nm

15: 1550nm

Fiber Length

A: 1 meter

S: Special

-

Pigtail Style

(=Package style)

B: bare fiber

L: 900

m

loose tube

Connector

0: None

1: FC/PC

2: FC/APC

3: SC/ PC

4: SC/APC

5: FC/SPC

6: SC/SPC

7: LC/UPC

8: LC/SPC

9: Special

A: FC/UPC

B: SC/UPC

C: ST

www.lightel.com

2210 Lind Ave SW, Suite 100

Renton, WA 98057 USA

(425) 277-8000 ph.

(425) 277-5280 Fax
