D100R
Series
Tightly Regulated
Miniature, 1W SIP
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
1W Output Power
•
Tight Line/Load Regulation
•
Miniature SIP Case
•
1,000 VDC Isolation
•
>2 MHour MTBF
•
20 Standard Models
•
Industry Standard Pin-Out
Input
Parameter
Conditions
5 VDC Input
Input Voltage Range
12 VDC Input
24 VDC Input
48 VDC Input
Input Filter
Reverse Polarity Input Current
Min.
4.5
10.8
21.6
44.0
Typ.
5.0
12.0
24.0
48.0
Max.
5.5
13.2
26.4
52.0
0.3
Conditions
For Vin Min to Max
50
120
±0.01
Momentary (0.5 Sec.)
Conditions
60 Seconds
500 VDC
100 kHz, 1V
Min.
1,000
1,000
60
60
Conditions
Ambient
Case
Min.
-40
-40
-40
Free Air Convection
RH, Non-condensing
95
%
Typ.
+25
Max.
+85
+100
+125
Typ.
Max.
Units
VDC
MΩ
pF
kHz
Units
ºC
ºC
ºC
±0.02
Min.
Typ.
Max.
±2.0
±0.5
±0.5
75
A
Units
%
%
%
mV P - P
%
%/ºC
VDC
Units
Internal Capacitor
Output
Parameter
Output Voltage Accuracy
Line Regulation
Load Regulation (Note 1)
Ripple & Noise (20 MHz) (Note 2)
Output Power Protection
Temperature Coefficient
Output Short Circuit
General
RoHS Compliant
Parameter
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
MicroPower Direct
Physical
292 Page Street
Suite D
Stoughton, MA 02072
USA
T: (781) 344-8226
F: (781) 344-8481
E: sales@micropowerdirect.com
W: www.micropowerdirect.com
Case Size
Case Material
Weight
0.76 x 0.28 x 0.39 Inches (19.5 x 7.2 x 10.0 mm)
Non-Conductive Black Plastic (UL94-V0)
0.07 Oz (2.1g)
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Conditions
5 VDC Input
12 VDC Input
24 VDC Input
48 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
2.0
Min.
-0.7
-0.7
-0.7
-0.7
Typ.
Max.
9.0
18.0
30.0
55.0
260
450
ºC
mW
VDC
Typ.
Max.
Units
MHours
Units
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
Caution: Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
Model Selection Guide
Model
Number
D101R
D102R
D103R
D104R
D105R
D111R
D112R
D113R
D114R
D115R
D121R
D122R
D123R
D124R
D125R
D131R
D132R
D133R
D134R
D135R
Input
Voltage (VDC)
Nominal
Range
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
5
4.5 - 5.5
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
12
10.8 - 13.2
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
24
21.6 - 26.4
48
44.0 - 52.0
48
44.0 - 52.0
48
44.0 - 52.0
48
44.0 - 52.0
48
44.0 - 52.0
Current (mA)
Full-Load No-Load
322
28
298
28
298
26
285
26
285
38
136
16
128
16
124
16
119
16
119
16
66
9
61
9
65
9
59
9
59
9
33
7
32
7
32
7
30
7
30
7
Voltage
(VDC)
3.3
5.0
9.0
12.0
15.0
3.3
5.0
9.0
12.0
15.0
3.3
5.0
9.0
12.0
15.0
3.3
5.0
9.0
12.0
15.0
Output
Current
(mA, Max)
200.0
200.0
111.0
83.0
66.0
200.0
200.0
111.0
83.0
66.0
200.0
200.0
111.0
83.0
66.0
200.0
200.0
111.0
83.0
66.0
Current
(mA, Min)
20.0
20.0
11.0
9.0
7.0
20.0
20.0
11.0
9.0
7.0
20.0
20.0
11.0
9.0
7.0
20.0
20.0
11.0
9.0
7.0
Efficiency
(%, Typ)
62
67
67
70
70
61
65
67
70
70
63
68
68
70
70
63
65
67
70
70
Fuse Rating
Slow-Blow
(mA)
500
500
500
500
500
200
200
200
200
200
100
100
100
100
100
100
100
100
100
100
Notes:
1. Output load regulation is specified for a load
change of 20% to 100%.
2. When measuring output ripple, it is recommended
that an external ceramic capacitor (approx 10 μF)
be placed from the +Vout pin to the -Vout pin.
3. The 5V, 12V and 24V input units do not require
external components to operate, but the use of an
input capacitor (10
μF)
may enhance performance
in some applications. An output capacitor (1.0
μF
to 10
μF)
may be used to reduce ripple. The 48V
input models require an input capacitor of 4.7
μF
to 47
μF
(dependent upon the application).
4. It is recommended that a fuse be used on the input
of a power supply for protection. See the table
above for the correct rating.
Mechanical Dimensions
Pin Connections
Pin
1
2
4
6
Function
+Vin
-Vin
-Vout
+Vout
Derating Curve
g
Capacitive
Load
(μF Max)
220
Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.01 (±0.25)
•
Pin 1 is marked by a “dot” or indentation on
the side of the unit
MicroPower Direct
www.micropowerdirect.com
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
