Amphenol
IC Socket Interconnects
G820
Materials
Housing
Contacts
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 1A
– 250VAC/rms 60Hz
DIP IC Socket PCB Mount Screw Machine Type
Durability
Gold Flash
10µ” Gold
15µ” Gold
30µ” Gold
100µ” Tin/lead
– 75 cycles
– 80 cycles
– 125 cycles
– 250 cycles
– 100 cycles
Low profile 2.54mm Pitch DIP IC Socket with screw-machine contacts.
Electrical
Current
Voltage
Part Number System:
G820 X XX X X
IC SOCKET DIP
PCB MOUNT 2.54mm Pitch
SPACE CODE
3: 7.62mm
6: 15.24
POSITIONS
Row spacing 7.62mm
06, 08, 14, 16, 18, 20, 24
Row spacing 15.24mm
24, 28, 32, 40
Space
Code
Pos.
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
CONTACT FINISH
0: flash Gold
1: 10µ” Gold
2: 15µ” Gold
3: 30µ” Gold
4: 100µ” Tin/Lead
AMTA Catalogue Page
3
3
3
3
3
3
6
8
14
16
18
20
A
7.62
10.16
17.78
20.32
22.86
25.40
Dimensions
B
C
10.16
5.08
10.16
7.62
10.16
15.24
10.16
17.78
10.16
20.32
10.16
22.86
D
7.62
7.62
7.62
7.62
7.62
7.62
Space
Code
Pos.
3
6
6
6
6
24
24
28
32
40
A
30.48
30.48
35.56
40.64
50.80
Dimensions
B
C
10.16
27.94
17.60
27.94
17.60
33.02
17.60
38.10
17.60
48.26
D
7.62
15.24
15.24
15.24
15.24
G818
Materials
Housing
Contacts
DIP IC Socket PCB Mount Stamped Contact Type
Durability
– 94V-0 thermoplastic
– P/B with 50µ” Ni
– 1A
– 250VAC/rms 60Hz
60µ” Tin/lead
100µ” Tin/lead
200µ” Tin/lead
– 50 cycles
– 100 cycles
– 250 cycles
Low cost 2.54mm Pitch DIP IC Socket with stamped contacts.
Electrical
Current
Voltage
Part Number System:
G818 X XX X X X
IC SOCKET DIP
PCB MOUNT 2.54mm Pitch
ROW SPACING
3: 7.62mm
4: 10.16mm
6: 15.24
9: 22.86mm
POSITIONS
Row spacing 7.62mm
06, 08, 14, 16, 18, 20, 22, 24, 28, 32
Row spacing 10.16mm
24, 28
Row spacing 15.24mm
24, 28, 32, 40, 42, 48
Row spacing 22.86mm
64
Space
Code
Pos.
Suffix may be added to Part Number.
This Suffix is for Internal use mainly.
Additional Suffix ‘EU’ or ‘LF’ may be
added for RoHS compliant product.
KINKED OPTION
0: Without kink
1: With kink
CONTACT FINISH
0: 60µ” Tin/lead
1: 100µ” Tin/lead
2: 200µ” Tin/lead
PNS-818 Rev. B
3
3
3
3
3
3
3
AMTA
6
8
14
16
18
20
24
A
7.62
10.16
17.78
20.32
22.86
25.40
30.48
Dimensions
B
C
9.96
5.08
9.96
7.62
9.96
15.24
9.96
17.78
9.96
20.32
9.96
22.86
9.96
27.94
D
7.62
7.62
7.62
7.62
7.62
7.62
7.62
Space
Code
Pos.
6
6
6
6
6
6
24
28
32
40
42
48
A
30.48
35.56
40.64
50.80
53.34
60.96
Dimensions
B
C
17.60
27.94
17.60
33.02
17.60
38.10
17.60
48.26
17.60
50.80
17.60
58.42
D
15.24
15.24
15.24
15.24
15.24
15.24
P-1
PCB Design
