Relay
FEATURES
•
•
•
•
•
•
Miniature,16-20 amps
UL,CSA, & TUV
VDE 8mm spacing,4 KV dielectric
TV 10,SPNO
5mm pinning
Flux-tight or Sealed
793
ORDERING INFORMATION
793-P
Type
Contact form
1A - SPNO
1B - SPNC
1C - S P D T
Enclosure
Blank - Flux-tight
S - Sealed
1C
S
12VDC
Coil voltage
Cover stamping color
White: 700mw coil
Yellow: 530mw coil
SAFETY APPROVAL
Certified
File No.
UL
E88991
CSA
LR90143
TUV
R9452019
SAFETY APPROVAL RATING
UL
1A
16A 250VAC
20A 125VAC
TV-10
20A 30VDC
1/2 HP, 125/250VAC
8A FLA,250VAC
1B,1C
16A 250VAC
20A 125VAC
16A 30VDC
1/2 HP, 125/250VAC
8A FLA,250VAC
CSA
1A
16A 250VAC
20A 125VAC
TV-10
20A 30VDC
1/2 HP, 125/250VAC
8A 250VAC
p.f. 0.4 - 0.5
1B,1C
16A 250VAC
20A 125VAC
16A 30VDC
1/2 HP, 125/250VAC
8A 250VAC
p.f. 0.4 - 0.5
TUV
1C
16A 250V~AC
16A 30V = DC
8A 250V~AC
COSø 0.4
COIL DATA HIGH SENSITIVITY (Yellow: 530mw coil)
Rated
voltage
(V)
3
5
6
9
12
18
24
48
60
110
Rated current
± 10 % at 25º
(mA)
176
105
88
60
44
29
22
11
8.8
5
Coil resistance
± 10 % at 25º
( )
17
47.7
68
150
275
618
1,100
4,400
6,800
23,100
Max. continuous
Pick up
voltage
voltage (Max)
25ºC
25ºC
Drop out
voltage (Min)
25ºC
Power consumption
at rated
voltage
110% of
rated
voltage
75% of
rated
voltage
10% of
rated
voltage
approx. 0.53W
Distributor: Electro-Stock, Inc. www.electrostock.com 800-876-1152 Fax: 630-876-1166 sales@electrostock.com
09
793
SPECIFICATION
Contact resistance
Operate time
Release time
Insulation resistance
Dielectric strength
Vibration resistance
Shock resistance
30m Max.(initial value)
10ms
5ms
100M Min.(DC 500V)
Between open contact
Between contact and coil
Relay
Life expectancy
Operating temperature
Weight
AC 1000V, 50/60Hz 1 min.
AC 4000V, 50/60Hz 1 min.(1B & 1C)
AC 5000V, 50/60Hz 1 min.(1A)
Operating extremes
10~50Hz,amplitude 1.5mm
Damage limits
>10~50Hz,amplitude 1.5mm
Operating extremes
>10G
Damage limits
>100G
>10,000,000 operations
Mechanical
(frequency 18,000 operations/hr)
>100,000 operations
Electrical
(frequency 1,800 operations/hr)
-40º ~ 70º C (no freezing)
Approx.17g
OUTLINE DIMENSIONS
WIRING DIAGRAM
PC BOARD LAYOUT
10
