BO LYMIN
BC1602F
Feature
1. COB with metal frame
2. 5x7 dots with cursor
3. Built-in controller KS0066 or equivalent
4. + 5V single power supply
5. 1/16 duty cycle
6. LED B/L pins:A/K, or 1/2
7. Option: LED array/edge B/L, EL B/L
8. Option: +3V single power supply
9. Option: negative voltage (built-in, external)
10.
Option: LCD Vop fix on 5V (-20
o
C~+70
o
C)
Mechanical Data
Item
Standard Value
Module Dimension
85.0 x 32.6
Viewing Area
66.0 x 16.0
Dot Size
0.55 x 0.65
Character Size
2.95 x 5.55
Pin Assignment
Pin
Symbol
1
Vss
2
Vdd
3
Vo
4
RS
5
R/W
6
E
7~14 DB0~7
Function
Unit
mm
mm
mm
mm
Electronic Characteristics
Item
Input Voltage
Supply Current
LCD Driving
Voltage
LED Forward
Voltage
Symbol Condition
Vdd
Idd
Vdd-Vo
Vf
If
If
Vel
Vdd = +5V
Vdd = +5V
70
o
C
25
o
C
o
Value
5.0
1.2
TYP
Unit
V
mA
GND
+5V(+3V option)
Contrast adjustment
H/L register select signal
H/L read/write signal
H --> L enable signal
H/L data bus line
-20 C
25
o
C
25
o
C
25
o
C
3.6
4.0
5.0
Option
5.0
5.0
5.0
V
V
mA
mA
V
4.2
100
20
EL Power
Voltage
Array LED
Forward Current
Edge LED
Forward
Current
Vel=110Vac/400Hz
Dimension
85.0
±
0.5
71.2
66.0(VA)
56.2(AA)
8.9(E
12.
/L)
L)
8.6 (LED B/L)
4.8 (EL or No B/L)
55
5
0.6
0.56
7
1.7
3.7
8.3
10.55
1.5
0.6
32.6
±
0.
2 9 .2
25.2
16 0(VA)
6-Ø1.0 PTH
0.4
43.5
2-R1.25 PTH
2-R2.5 PAD
79.0
1.6
T SIZE
SCALE 5/1
3.0
5.95
5.55
0.7
0.66
