74ALVC162245 Low Voltage 16-Bit Bidirectional Transceiver with 3.6V Tolerant Inputs and Outputs and 26Ω
Series Resistors in A Port Outputs
October 2001
Revised November 2001
74ALVC162245
Low Voltage 16-Bit Bidirectional Transceiver
with 3.6V Tolerant Inputs and Outputs
and 26
Ω
Series Resistors in A Port Outputs
General Description
The ALVC162245 contains sixteen non-inverting bidirec-
tional buffers with 3-STATE outputs and is intended for bus
oriented applications. The device is byte controlled. Each
byte has separate 3-STATE control inputs which can be
shorted together for full 16-bit operation. The T/R inputs
determine the direction of data flow through the device.
The OE inputs disable both the A and B Ports by placing
them in a high impedance state.
The 74ALVC162245 is designed for low voltage (1.65V to
3.6V) V
CC
applications with I/O compatibility up to 3.6V.
The 74ALVC162245 is also designed with 26
Ω
series
resistance in the A Port outputs. This design reduces line
noise in applications such as memory address drivers,
clock drivers, and bus transceivers/transmitters.
The 74ALVC162245 is fabricated with an advanced CMOS
technology to achieve high speed operation while maintain-
ing low CMOS power dissipation.
Features
I
1.65V–3.6V V
CC
supply operation
I
3.6V tolerant inputs and outputs
I
26
Ω
series resistors in A Port outputs
I
t
PD
3.9 ns max for 3.0V to 3.6V V
CC
4.8 ns max for 2.3V to 2.7V V
CC
8.6 ns max for 1.65V to 1.95V V
CC
I
Power-down high impedance inputs and outputs
I
Supports live insertion/withdrawal (Note 1)
I
Uses patented noise/EMI reduction circuitry
I
Latchup conforms to JEDEC JED78
I
ESD performance:
Human body model
>
2000V
Machine model
>
200V
Note 1:
To ensure the high-impedance state during power up or power
down, OE should be tied to V
CC
through a pull-up resistor; the minimum
value of the resistor is determined by the current-sourcing capability of the
driver.
Ordering Code:
Order Number
74ALVC162245T
Package Number
MTD48
Package Description
48-Lead Thin Shrink Small Outline Package (TSSOP), JEDEC MO-153, 6.1mm Wide
Devices also available in Tape and Reel. Specify by appending the suffix letter “X” to the ordering code.
© 2001 Fairchild Semiconductor Corporation
DS500679
www.fairchildsemi.com
74ALVC162245
Absolute Maximum Ratings
(Note 2)
Supply Voltage (V
CC
)
DC Input Voltage (V
I
)
Output Voltage (V
O
) (Note 3)
DC Input Diode Current (I
IK
)
V
I
<
0V
DC Output Diode Current (I
OK
)
V
O
<
0V
DC Output Source/Sink Current
(I
OH
/I
OL
)
DC V
CC
or GND Current per
Supply Pin (I
CC
or GND)
Storage Temperature Range (T
STG
)
−
0.5V to
+
4.6V
−
0.5V to 4.6V
−
0.5V to V
CC
+
0.5V
−
50 mA
−
50 mA
±
50 mA
±
100 mA
−
65
°
C to
+
150
°
C
Recommended Operating
Conditions
(Note 4)
Power Supply
Operating
Input Voltage
Output Voltage (V
O
)
Free Air Operating Temperature (T
A
)
Minimum Input Edge Rate (
∆
t/
∆
V)
V
IN
=
0.8V to 2.0V, V
CC
=
3.0V
10 ns/V
Note 2:
The Absolute Maximum Ratings are those values beyond which
the safety of the device cannot be guaranteed. The device should not be
operated at these limits. The parametric values defined in the Electrical
Characteristics tables are not guaranteed at the Absolute Maximum Rat-
ings. The “Recommended Operating Conditions” table will define the condi-
tions for actual device operation.
Note 3:
I
O
Absolute Maximum Rating must be observed.
Note 4:
Floating or unused control inputs must be held HIGH or LOW.
1.65V to 3.6V
0V to V
CC
0V to V
CC
−
40
°
C to
+
85
°
C
DC Electrical Characteristics
Symbol
V
IH
Parameter
HIGH Level Input Voltage
Conditions
V
CC
(V)
1.65 - 1.95
2.3 - 2.7
2.7 - 3.6
V
IL
LOW Level Input Voltage
1.65 - 1.95
2.3 - 2.7
2.7 - 3.6
V
OH
HIGH Level Output Voltage
A Outputs
I
OH
= −100 µA
I
OH
= −2
mA
I
OH
= −4
mA
I
OH
= −6
mA
I
OH
= −8
mA
I
OH
= −12
mA
HIGH Level Output Voltage
B Outputs
I
OH
= −100 µA
I
OH
= −4
mA
I
OH
= −6
mA
I
OH
= −12
mA
1.65 - 3.6
1.65
2.3
2.3
3.0
2.7
3.0
1.65 - 3.6
1.65
2.3
2.3
2.7
3.0
I
OH
= −24
mA
V
OL
LOW Level Output Voltage
A Outputs
I
OL
=
100
µA
I
OL
=
2 mA
I
OL
=
4 mA
I
OL
=
6 mA
I
OL
=
8 mA
I
OL
=
12 mA
LOW Level Output Voltage
B Outputs
I
OL
=
100
µA
I
OL
=
4 mA
I
OL
=
6 mA
I
OL
=
12 mA
I
OL
=
24 mA
I
I
I
OZ
Input Leakage Current
3-STATE Output Leakage
0
≤
V
I
≤
3.6V
0
≤
V
O
≤
3.6V, V
I
=
V
IH
or V
IL
3.0
1.65 - 3.6
1.65
2.3
2.3
3.0
2.7
3.0
1.65 - 3.6
1.65
2.3
2.3
2.7
3.0
1.65 - 3.6
1.65 - 3.6
V
CC
- 0.2
1.2
1.9
1.7
2.4
2
2
V
CC
- 0.2
1.2
2.0
1.7
2.2
2.4
2
0.2
0.45
0.4
0.55
0.55
0.6
0.8
0.2
0.45
0.4
0.7
0.4
0.55
±5.0
±10
µA
µA
V
V
Min
0.65 x V
CC
1.7
2.0
0.35 x V
CC
0.7
0.8
V
V
Max
Units
3
www.fairchildsemi.com
