JANS1N4573AUR-1 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> JANS1N4573AUR-1

Preview

JANS1N4573AUR-1: DescriptionZener Diode, 6.4V V(Z), 5%, 0.5W, Silicon, DO-213AA, HERMETIC SEALED, GLASS PACKAGE-2; CategoryDiscrete semiconductor diode; File Size248KB，2 Pages; ManufacturerCompensated Devices Inc.

Download Datasheet Parametric View All

JANS1N4573AUR-1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JANS1N4573AUR-1	-	-	View	Buy Now

JANS1N4573AUR-1 Overview

Zener Diode, 6.4V V(Z), 5%, 0.5W, Silicon, DO-213AA, HERMETIC SEALED, GLASS PACKAGE-2

JANS1N4573AUR-1 Parametric

Parameter Name	Attribute value
Maker	Compensated Devices Inc.
package instruction	O-LELF-R2
Reach Compliance Code	unknown
Is Samacsys	N
Other features	METALLURGICALLY BONDED
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JEDEC-95 code	DO-213AA
JESD-30 code	O-LELF-R2
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-65 °C
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Guideline	MIL-19500/452G
Nominal reference voltage	6.4 V
surface mount	YES
technology	ZENER
Terminal form	WRAP AROUND
Terminal location	END
Voltage temperatureCoeff-Max	0.064 mV/°C
Maximum voltage tolerance	5%
Working test current	1 mA
Base Number Matches	1

Preview

Download Datasheet

View All

• 1N4565AUR-1 THRU 1N4584AUR-1 AVAILABLE IN

JAN, JANTX, JANTXV AND JANS 1N4565AUR-1 thru 1N4584AUR-1

PER MIL-PRF-19500/452

and

• TEMPERATURE COMPENSATED ZENER REFERENCE DIODES

• LEADLESS PACKAGE FOR SURFACE MOUNT

• LOW CURRENT OPERATING RANGE: 0.5 TO 4.0 mA

• METALLURGICALLY BONDED, DOUBLE PLUG CONSTRUCTION

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +175°C

DC Power Dissipation: 500mW @ +50°C

Power Derating: 4 mW / °C above +50°C

CDLL4565 thru CDLL4584A

REVERSE LEAKAGE CURRENT

lR = 2

µ

A @ 25°C & VR = 3Vdc

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise speciﬁed.

CDI

TYPE

NUMBER

ZENER

TEST

CURRENT

l ZT

EFFECTIVE

TEMPERATURE

COEFFICIENT

VOLTAGE

TEMPERATURE

STABILITY

∆V

ZT MAX

-55° to + 100°

(Note 1)

mV

48

100

24

50

10

20

5

10

2.5

5

48

100

24

50

10

20

5

10

2.5

5

48

100

24

50

10

20

5

10

2.5

5

48

100

24

50

10

20

5

10

2.5

5

TEMPERATURE

RANGE

MAX.DYNAMIC

ZENER

IMPEDANCE

ZZT

(Note 2)

°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

0 to + 75°C

-55 to + 100°C

OHMS

200

100

50

25

mA

CDLL4565

CDLL4565A

CDLL4566

CDLL4566A

CDLL4567

CDLL4567A

CDLL4568

CDLL4568A

CDLL4569

CDLL4569A

CDLL4570

CDLL4570A

CDLL4571

CDLL4571A

CDLL4572

CDLL4572A

CDLL4573

CDLL4573A

CDLL4574

CDLL4574A

CDLL4575

CDLL4575A

CDLL4576

CDLL4576A

CDLL4577

CDLL4577A

CDLL4578

CDLL4578A

CDLL4579

CDLL4579A

CDLL4580

CDLL4580A

CDLL4581

CDLL4581A

CDLL4582

CDLL4582A

CDLL4583

CDLL4583A

CDLL4584

CDLL4584A

.5

1.0

2.0

4.0

%/°C

.01

.005

.002

.001

.0005

.01

.005

.002

.001

.0005

.01

.005

.002

.001

.0005

.01

.005

.002

.001

.0005

MILLIMETERS

INCHES

DIM MIN MAX MIN MAX

D

1.60

1.70 0.063 0.067

F

0.41

0.55 0.016 0.022

G

3.30

3.70 .130 .146

G1

2.54 REF.

.100 REF.

S

0.03 MIN.

.001 MIN.

FIGURE 1

DESIGN DATA

CASE:

DO-213AA, Hermetically sealed

glass case. (MELF, SOD-80, LL34)

LEAD FINISH:

Tin / Lead

POLARITY:

Diode to be operated with

the banded (cathode) end positive.

MOUNTING POSITION:

Any.

MOUNTING SURFACE SELECTION:

The Axial Coefficient of Expansion

(COE) Of this Device is Approximately

+6PPM/°C. The COE of the Mounting

Surface System Should Be Selected To

Provide A Suitable Match With This

Device.

NOTE 1

The maximum allowable change observed over the entire temperature range

i.e.,the diode voltage will not exceed the speciﬁed mV at any discrete

temperature between the established limits, per JEDEC standard No.5.

NOTE 2

Zener impedance is derived by superimposing on l ZT A 60Hz rms a.c. current

equal to 10% of l ZT.

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
