74HC597 datasheet, PDF - EEWORLD Datasheet

74HC597: Description8-bit shift register with input flip-flops; File Size78KB，12 Pages; ManufacturerPhilips Semiconductors (NXP Semiconductors N.V.); Websitehttps://www.nxp.com/

Download Datasheet Compare View All

74HC597 Overview

8-bit shift register with input flip-flops

INTEGRATED CIRCUITS

DATA SHEET

For a complete data sheet, please also download:

•

The IC06 74HC/HCT/HCU/HCMOS Logic Family Specifications

•

The IC06 74HC/HCT/HCU/HCMOS Logic Package Information

•

The IC06 74HC/HCT/HCU/HCMOS Logic Package Outlines

74HC/HCT597

8-bit shift register with input

flip-flops

Product speciﬁcation

File under Integrated Circuits, IC06

December 1990

	74HC597	74HC597D	74HC597N	74HCT597	74HCT597N
Description	8-bit shift register with input flip-flops	8-bit shift register with input flip-flops	8-bit shift register with input flip-flops	8-bit shift register with input flip-flops	8-bit shift register with input flip-flops
Is it Rohs certified?	-	conform to	conform to	-	conform to
Maker	-	Philips Semiconductors (NXP Semiconductors N.V.)	Philips Semiconductors (NXP Semiconductors N.V.)	-	Philips Semiconductors (NXP Semiconductors N.V.)
package instruction	-	SOP, SOP16,.25	DIP, DIP16,.3	-	DIP, DIP16,.3
Reach Compliance Code	-	unknown	unknow	-	unknow
JESD-30 code	-	R-PDSO-G16	R-PDIP-T16	-	R-PDIP-T16
Number of digits	-	8	8	-	8
Number of functions	-	1	1	-	1
Number of terminals	-	16	16	-	16
Maximum operating temperature	-	85 °C	85 °C	-	85 °C
Minimum operating temperature	-	-40 °C	-40 °C	-	-40 °C
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY
encapsulated code	-	SOP	DIP	-	DIP
Encapsulate equivalent code	-	SOP16,.25	DIP16,.3	-	DIP16,.3
Package shape	-	RECTANGULAR	RECTANGULAR	-	RECTANGULAR
Package form	-	SMALL OUTLINE	IN-LINE	-	IN-LINE
power supply	-	2/6 V	2/6 V	-	5 V
Certification status	-	Not Qualified	Not Qualified	-	Not Qualified
surface mount	-	YES	NO	-	NO
technology	-	CMOS	CMOS	-	CMOS
Temperature level	-	INDUSTRIAL	INDUSTRIAL	-	INDUSTRIAL
Terminal form	-	GULL WING	THROUGH-HOLE	-	THROUGH-HOLE
Terminal pitch	-	1.27 mm	2.54 mm	-	2.54 mm
Terminal location	-	DUAL	DUAL	-	DUAL
