JANTXV1N5314UR-1 datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> JANTXV1N5314UR-1

JANTXV1N5314UR-1: DescriptionCurrent Regulator Diode, 4.7mA I(S), 2.9V V(L), Silicon, DO-213AB, HERMETIC SEALED PACKAGE-2; CategoryDiscrete semiconductor diode; File Size28KB，2 Pages; ManufacturerCompensated Devices Inc.

Download Datasheet Parametric View All

JANTXV1N5314UR-1 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JANTXV1N5314UR-1	-	-	View	Buy Now

JANTXV1N5314UR-1 Overview

Current Regulator Diode, 4.7mA I(S), 2.9V V(L), Silicon, DO-213AB, HERMETIC SEALED PACKAGE-2

JANTXV1N5314UR-1 Parametric

Parameter Name	Attribute value
Maker	Compensated Devices Inc.
package instruction	HERMETIC SEALED PACKAGE-2
Reach Compliance Code	unknown
Is Samacsys	N
Other features	METALLURGICALLY BONDED
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	CURRENT REGULATOR DIODE
JEDEC-95 code	DO-213AB
JESD-30 code	O-XELF-R2
Maximum knee impedance	12000 Ω
Maximum limit voltage	2.9 V
Number of components	1
Number of terminals	2
Maximum operating temperature	175 °C
Minimum operating temperature	-65 °C
Package body material	UNSPECIFIED
Package shape	ROUND
Package form	LONG FORM
Maximum power dissipation	0.5 W
Certification status	Not Qualified
Guideline	MIL-19500/463G
Nominal regulation current (Ireg)	4.7 mA
Maximum repetitive peak reverse voltage	100 V
surface mount	YES
technology	FIELD EFFECT
Terminal form	WRAP AROUND
Terminal location	END
Base Number Matches	1

Preview

Download Datasheet

View All

• 1N5283UR-1 THRU 1N5314UR-1 AVAILABLE IN

JAN

JANTX, JANTXV AND JANS 1N5283UR-1 thru 1N5314UR-1

PER MIL-PRF-19500/463

• CURRENT REGULATOR DIODES

• LEADLESS PACKAGE FOR SURFACE MOUNT

• METALLURGICALLY BONDED

• DOUBLE PLUG CONSTRUCTION

and

CDLL5283 thru CDLL5314

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +175°C

DC Power Dissipation: 500mW @ +75°C @ TEC = +125°C

Power Derating: 10 mW / °C above TEC = +125°C

Peak Operating Voltage: 100 Volts

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified

CDI

TYPE

NUMBER

NOM

CDLL5283

CDLL5284

CDLL5285

CDLL5286

CDLL5287

CDLL5288

CDLL5289

CDLL5290

CDLL5291

CDLL5292

CDLL5293

CDLL5294

CDLL5295

CDLL5296

CDLL5297

CDLL5298

CDLL5299

CDLL5300

CDLL5301

CDLL5302

CDLL5303

CDLL5304

CDLL5305

CDLL5306

CDLL5307

CDLL5308

CDLL5309

CDLL5310

CDLL5311

CDLL5312

CDLL5313

CDLL5314

0.22

0.24

0.27

0.30

0.33

0.39

0.43

0.47

0.56

0.62

0.68

0.75

0.82

0.91

1.00

1.10

1.20

1.30

1.40

1.50

1.60

1.80

2.00

2.20

2.40

2.70

3.00

3.30

3.60

3.90

4.30

4.70

REGULATOR CURRENT

l p (mA) @ VS = 25V

MIN

0.198

0.216

0.243

0.270

0.297

0.351

0.387

0.423

0.504

0.558

0.612

0.675

0.738

0.819

0.900

0.990

1.08

1.17

1.26

1.35

1.44

1.62

1.80

1.98

2.16

2.43

2.70

2.97

3.24

3.51

3.87

4.23

MAX

0.242

0.264

0.297

0.330

0.363

0.429

0.473

0.517

0.616

0.682

0.748

0.825

0.902

1.001

1.100

1.210

1.32

1.43

1.54

1.65

1.76

1.98

2.20

2.42

2.64

2.97

3.30

3.63

3.96

4.29

4.73

5.17

MINIMUM

DYNAMIC

IMPEDANCE

@VS = 25V

ZS (MΩ)

(Note 1)

25.0

19.0

14.0

9.0

6.6

4.10

3.30

2.70

1.90

1.55

1.35

1.15

1.00

0.880

0.800

0.700

0.640

0.580

0.540

0.510

0.475

0.420

0.395

0.370

0.345

0.320

0.300

0.280

0.265

0.255

0.245

0.235

MINIMUM

KNEE

IMPEDANCE

@VK = 6.0 V

ZK (MΩ)

(Note 2)

2.75

2.35

1.95

1.60

1.35

1.00

0.870

0.750

0.560

0.470

0.400

0.335

0.290

0.240

0.205

0.180

0.155

0.135

0.115

0.105

0.092

0.074

0.061

0.052

0.044

0.035

0.029

0.024

0.020

0.017

0.014

0.012

MAXIMUM

LIMITING

VOLTAGE

@ lL = 0.8 lp (min)

VL (VOLTS)

1.00

1.05

1.10

1.13

1.15

1.20

1.25

1.29

1.35

1.40

1.45

1.50

1.55

1.60

1.65

1.75

1.85

1.95

2.00

2.15

2.25

2.35

2.50

2.60

2.75

2.90

MILLIMETERS

DIM MIN MAX

2.39

2.66

0.41

0.55

4.80

5.20

4.11 REF.

0.03 MIN.

INCHES

MIN MAX

.094 .105

.016 .022

.189 .205

.159 REF.

.001 MIN.

FIGURE 1

DESIGN DATA

CASE:

DO-213AB, Hermetically sealed

glass case. (MELF, LL41)

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE: (R

OJEC):

50 ˚C/W maximum at L = 0 inch

THERMAL IMPEDANCE: (Z

OJX): 25

˚C/W maximum

POLARITY:

Diode to be operated with

the banded (cathode) end negative.

MOUNTING SURFACE SELECTION:

The Axial Coefficient of Expansion

(COE) Of this Device is Approximately

+6PPM/°C. The COE of the Mounting

Surface System Should Be Selected To

Provide A Suitable Match With This

Device.

NOTE 1

NOTE 2

ZS is derived by superimposing A 90Hz RMS signal equal to 10% of VS on VS

ZK is derived by superimposing A 90Hz RMS signal equal to 10% of VK on VK

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
