74HC/HCT7404
5-Bit x 64-word FIFO register;
3-state
Product specification
Supersedes data of October 1990
File under Integrated Circuits, IC06
September 1993
Philips Semiconductors
Product specification
5-Bit x 64-word FIFO register; 3-state
FEATURES
•
Synchronous or asynchronous operation
•
3-state outputs
•
30 MHz (typical) shift-in and shift-out rates
•
Readily expandable in word and bit dimensions
•
Pinning arranged for easy board layout: input pins
directly opposite output pins
•
Output capability: driver (8 mA)
•
I
CC
category: LSI.
APPLICATIONS
•
High-speed disc or tape controller
•
Communications buffer.
GENERAL DESCRIPTION
74HC/HCT7404
The 74HC/HCT7404 are high-speed Si-gate CMOS
devices specified in compliance with JEDEC standard
no.7A.
The “7404” is an expandable, First-In First-Out (FIFO)
memory organized as 64 words by 5 bits. A guaranteed
15 MHz data-rate makes it ideal for high-speed
applications. A higher data-rate can be obtained in
applications where the status flags are not used
(burst-mode).
With separate controls for shift-in (SI) and shift-out (SO),
reading and writing operations are completely
independent, allowing synchronous and asynchronous
data transfers. Additional controls include a master-reset
input (MR), an output enable input (OE) and flags. The
data-in-ready (DIR) and data-out-ready (DOR) flags
indicate the status of the device.
QUICK REFERENCE DATA
GND = 0 V; T
amb
= 25
°C;
t
r
= t
f
= 6 ns.
TYP.
SYMBOL
t
PHL
/t
PLH
f
max
C
I
C
PD
Note
1. For HC the condition is V
I
= GND to V
CC
.
For HCT the condition is V
I
= GND to V
CC
−1.5
V.
ORDERING INFORMATION
EXTENDED
TYPE NUMBER
74HC/HCT7404N
74HC/HCT7404D
PACKAGE
PINS
18
20
PIN POSITION
DIL
SO20
MATERIAL
plastic
plastic
CODE
SOT102
SOT163A
PARAMETER
propagation delay SO, SI to DIR and DOR
maximum clock frequency
input capacitance
power dissipation capacitance per package
note 1
CONDITIONS
HC
C
L
= 15 pF; V
CC
= 5 V
15
30
3.5
475
HCT
17
30
3.5
490
ns
MHz
pF
pF
UNIT
September 1993
2
Philips Semiconductors
Product specification
5-Bit x 64-word FIFO register; 3-state
PINNING (SOT102)
SYMBOL
OE
DIR
SI
D
O
to D
4
GND
MR
Q
4
to Q
0
DOR
SO
V
CC
PIN
1
2
3
9
10
11, 12, 13,
14, 15
16
17
18
DESCRIPTION
output enable input (active
LOW)
data-in-ready output
shift-in input (active HIGH)
ground
asynchronous master-reset
input (active LOW)
data outputs
Q
4
to Q
0
data-out-ready output
shift-out input (active LOW)
positive supply voltage
n.c.
DOR
n.c.
V
CC
12, 13, 14,
15, 16
17
18
19
20
PINNING (SOT163A)
SYMBOL
OE
DIR
SI
n.c.
D
0
to D
4
GND
MR
PIN
1
2
3
4
10
11
74HC/HCT7404
DESCRIPTION
output enable input (active
LOW)
data-in-ready output
shift-in input (active HIGH)
not connected
ground
asynchronous master-reset
input (active LOW)
data outputs
not connected
data-out ready output
not connected
positive supply voltage
4, 5, 6, 7, 8 parallel data inputs
5, 6, 7, 8, 9 parallel data inputs
handbook, halfpage
handbook, halfpage
OE
OE
DIR
SI
D0
D1
D2
D3
D4
GND
1
2
3
4
5
6
7
8
9
MGA670
1
2
3
4
5
18 V
CC
17 SO
20 V
CC
19 SO
18 DOR
17 n.c.
16 Q0
DIR
SI
16 DOR
n.c.
15 Q0
D0
D1
D2
D3
D4
7404
14 Q1
13 Q2
12 Q3
11 Q4
10 MR
7404
6
7
8
9
15 Q1
14 Q2
13 Q3
12 Q4
11 MR
MGA671
GND 10
Fig.1 Pin configuration (SOT102).
Fig.2 Pin configuration (SOT163).
September 1993
3
Philips Semiconductors
Product specification
5-Bit x 64-word FIFO register; 3-state
74HC/HCT7404
handbook, halfpage
1 (1)
handbook, halfpage
FIFO 64 x 5
EN4
1Z3
[IR] 3
[OR] 6
G1
G5
2 (2)
16 (18)
(1) 1
OE
(5) 4
(6) 5
(7) 6
(8) 7
(9) 8
D0
D1
D2
D3
D4
SI
SO
MR
10 (11)
MGA673
Q0
Q1
Q2
Q3
Q4
DOR
DIR
15 (16)
14 (15)
13 (14)
12 (13)
11 (12)
(5) 4
(6) 5
(7) 6
(8) 7
(9) 8
(3) 3
(11) 10
(19) 17
CTR
1 ( /C2) CT
<
64
CT = 0
CT
>
0
5
5Z6
2D
(3) 3
(19) 17
16 (18)
2 (2)
4
15 (16)
14 (15)
13 (14)
12 (13)
11 (12)
MGA675
Pin numbers between parentheses refer to the SO package.
Pin numbers between parentheses refer to the SO package.
Fig.3 Logic symbol.
Fig.4 IEC logic symbol.
handbook, full pagewidth
(5) 4 D0
(6) 5 D1
(7) 6 D2
(8) 7 D3
(9) 8 D4
INPUT
STAGE
1 x 5 BITS
MAIN FIFO
REGISTER
62 x 5 BITS
OUTPUT
STAGE
1 x 5 BITS
OE
Q 0 15 (16)
Q 1 14 (15)
Q 2 13 (14)
Q 3 12 (13)
Q 4 11 (12)
(11) 10 MR
DIR
2 (2)
SI
CONTROL LOGIC
DOR
SO
OE
1 (1)
MGA680
3 (3)
16 (18) 17 (19)
Pin numbers between parentheses refer to the SO package.
Fig.5 Functional diagram.
September 1993
4
full pagewidth
R (1)
R
DOR
S
Q
FP
September 1993
SO
Philips Semiconductors
MR
61 x
SI
(1)
R
R FF2
S
Q
S
Q
S
Q
S
R
FF3
to
FF63
R FF64
R
FB
Q
Q
R
Q
R
Q
(2)
(2)
(2)
(1)
R
Q
R
FS
R FF1
5-Bit x 64-word FIFO register; 3-state
S
Q
S
Q
5
OE
CL
CL
CL
CL
CL
CL
Q0
Q1
5
LATCHES
5
LATCHES
5
LATCHES
3-STATE
OUTPUT
BUFFER
Q3
Q4
position 2
position 3 to 63
position 64
MSB117
DIR
D0
CL
CL
D1
5
LATCHES
D3
D4
position 1
(See control flip-flops)
LOW on S input of flip-flops FS, FB and FP will set Q output to HIGH independent of state on R input.
LOW on R input of FF1 to FF64 will set Q output to LOW independent of state on S input.
74HC/HCT7404
Product specification
Fig.6 Logic diagram.
