A500RHI
Series
Very High Isolation, 5W
Single & Dual Output
DC/DC Converters
Electrical Specifications
Specifications typical @ +25°C, nominal input voltage & rated output current, unless otherwise noted. Specifications subject to change without notice.
Key Features:
•
5W Output Power
•
5,600 VDC Isolation
•
2 µA Leakage Current Max
•
Wide 2:1 Input Range
•
Compact DIP Case
•
Single & Dual Outputs
•
Meets EN55022
•
700 kH MTBF
•
EN60950 Approved
Input
Parameter
Input Start Voltage
Conditions
Min.
Typ.
Max.
12 VDC Input
7.0
8.0
9.0
24 VDC Input 13.0
15.0
18.0
48 VDC Input 30.0
33.0
36.0
12 VDC Input
8.5
24 VDC Input
16.0
48 VDC Input
34.0
(Pi) Filter (Complies with EN55022 Class A)
0.3
3,000
Conditions
Dual Output , Balanced Loads
Vin = Min to Max
Iout = 10% to 100%
5V Output
All Other Outputs
Over Line, Load & Temp.
120
50% Load Step Change
300
±3.0
±0.02
Continuous (Autorecovery)
Min.
5,600
6,000
1,000
7
150
13
Typ.
500
±6.0
±0.05
Min.
Typ.
±0.5
±0.5
±0.3
±0.5
75
100
Max.
±1.0
±2.0
±0.5
±1.0
100
150
180
25
Units
VDC
Under Voltage Shutdown
Input Filter
Reverse Polarity Input Current
Short Circuit Input Power
VDC
A
mW
Units
%
%
%
%
mV P - P
mV P - P
mV rms
%
µSec
%
%/ºC
Output
Parameter
Output Voltage Accuracy
Output Voltage Balance
Line Regulation
Load Regulation
Ripple & Noise (20 MHz) (Note 1)
Ripple & Noise (20 MHz)
Ripple & Noise (20 MHz)
Output Power Protection
Transient Recovery Time (Note 2)
Transient Response Deviation
Temperature Coefficient
Output Short Circuit
General
Parameter
Isolation Voltage, Rated
Isolation Test Voltage
Leakage Current
Isolation Resistance
Isolation Capacitance
Switching Frequency
Conditions
60 Seconds
60 Seconds
240 VAC, 60 Hz
500 VDC
100 kHz, 1V
Max.
Units
VDC
VDC
µA
M
pF
kHz
Units
ºC
ºC
ºC
%
2
Environmental
Parameter
Operating Temperature Range
Operating Temperature Range
Storage Temperature Range
Cooling
Humidity
Conditions
Min.
Typ.
Ambient
-40
Case
-40
-40
Free Air Convection
RH, Non-condensing
Max.
+55
+95
+125
95
MicroPower Direct
292 Page Street
Suite D
Stoughton, MA 02072
USA
T:
(781) 344-8226
F:
(781) 344-8481
E:
sales@micropowerdirect.com
W:
www.micropowerdirect.com
Physical
Case Size
Case Material
Weight
1.25 x 0.80 x 0.40 Inches (31.8 x 20.3 x 10.2 mm)
Non-Conductive Black Plastic (UL94-V0)
0.57 Oz (16.2g)
Conditions
MIL HDBK 217F, 25ºC, Gnd Benign
Conditions
12 VDC Input
24 VDC Input
48 VDC Input
1.5 mm From Case For 10 Sec
All Models
Min.
700
Min.
-0.7
-0.7
-0.7
Typ.
Max.
Units
kHours
Units
VDC
º
C
Reliability Specifications
Parameter
MTBF
Absolute Maximum Ratings
Parameter
Input Voltage Surge (1 Sec)
Lead Temperature
Internal Power Dissipation
Typ.
Max.
25.0
50.0
100.0
260
2,500
mW
Caution:
Exceeding Absolute Maximum Ratings may damage the module. These are not continuous operating ratings.
www.micropowerdirect.com
Model Selection Guide
Input
Model
Number
A501RHI
A502RHI
A503RHI
A504RHI
A511RHI
A512RHI
A513RHI
A514RHI
A521RHI
A522RHI
A523RHI
A524RHI
Voltage (VDC)
Nominal
12
12
12
12
24
24
24
24
48
48
48
48
Range
9.0 - 18.0
9.0 - 18.0
9.0 - 18.0
9.0 - 18.0
18.0 - 36.0
18.0 - 36.0
18.0 - 36.0
18.0 - 36.0
36.0 - 75.0
36.0 - 75.0
36.0 - 75.0
36.0 - 75.0
www.micropowerdirect.com
Output
Reflected
Fuse Rating
Efficiency
Ripple
Current (mA)
Slow-Blow
Current
(%, Typ)
Current Voltage Current
(mA)
Full-Load No-Load
(mA, Typ)
(VDC) (mA, Max) (mA, Min)
570
641
641
641
278
313
313
313
139
156
156
156
30
30
30
30
20
20
20
20
10
10
10
10
60
60
60
60
30
30
30
30
15
15
15
15
5.0
12.0
±12.0
±15.0
5.0
12.0
±12.0
±15.0
5.0
12.0
±12.0
±15.0
1,000
500
±250
±200
1,000
500
±250
±200
1,000
500
±250
±200
200.0
100.0
±50.0
±40.0
200.0
100.0
±50.0
±40.0
200.0
100.0
±50.0
±40.0
75
78
78
78
77
80
80
80
77
80
80
80
1,200
1,200
1,200
1,200
600
600
600
600
300
300
300
300
Notes:
1.
When measuring output ripple, it is recommended that an external 0.47
µF
ceramic capacitor be
placed from the +Vout pin to the -Vout pin for single output units and from each output to common
for dual output units. For noise sensitive applications, the use of 3.3
µF
capacitors will reduce the
output ripple.
2.
Transient recovery is measured to within a 1% error band for a load step change of 75% to 100%.
3.
Dual output units may be connected to provide a 24 VDC or 30 VDC output. To do this, connect the
load across the positive (+Vout) and negative (-Vout) outputs and float the output common.
4.
The converter should be connected to a low ac-impedance source. An input source with a highly
inductive impedance may affect the stability of the converter. In applications where the converter
output loading is high and input power is supplied over long lines, it may be necessary to use a
capacitor on the input to insure start-up.
In this case, it is recommended that a low ESR (ESR <1.0 at 100 kHz) capacitor be mounted close
to the converter. For 12V input units a 10.0
µF
is recommended, for 24V a 4.7
µF
and for 48V units
a 2.2
µF.
5.
It is recommended that a fuse be used on the input of a power supply for protection. See the table
above for the correct rating.
Derating Curve
- 5V Output
Mechanical Dimensions
Derating Curve
- All Other Outputs
Mechanical Notes:
•
All dimensions are typical in inches (mm)
•
Tolerance x.xx = ±0.01 (±0.25)
Pin Connections
Pin
1
11
±15 Out
±220
12
13
Single
+Vin
No Pin
-Vout
+Vout
Dual
+Vin
Common
No Pin
-Vout
Pin
15
23
24
Single
No Pin
-Vin
-Vin
Dual
+Vout
-Vin
-Vin
Capacitive Load
-
µF
Max
5V Out
1,000
12V Out
470
±12 Out
±220
MicroPower Direct
We Power Your Success - For Less!
292 Page Street Ste D Stoughton, MA 02072
•
TEL: (781) 344-8226
•
FAX: (781) 344-8481
•
E-Mail: sales@micropowerdirect.com
