SE5532AFE-B

Description
Operational Amplifier, 2 Func, 3000uV Offset-Max, BIPolar, CDIP8
CategoryAnalog mixed-signal IC    Amplifier circuit
File Size416KB,6 Pages
ManufacturerPhilips Semiconductors (NXP Semiconductors N.V.)
Websitehttps://www.nxp.com/
Download Datasheet Parametric View All

SE5532AFE-B Overview

Operational Amplifier, 2 Func, 3000uV Offset-Max, BIPolar, CDIP8

SE5532AFE-B Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
Reach Compliance Codeunknown
Amplifier typeOPERATIONAL AMPLIFIER
ArchitectureVOLTAGE-FEEDBACK
Maximum bias current (IIB) at 25C0.4 µA
frequency compensationYES
Maximum input offset voltage3000 µV
JESD-30 codeR-XDIP-T8
JESD-609 codee0
low-dissonanceNO
Nominal Negative Supply Voltage (Vsup)-15 V
Number of functions2
Number of terminals8
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Package body materialCERAMIC
encapsulated codeDIP
Encapsulate equivalent codeDIP8,.3
Package shapeRECTANGULAR
Package formIN-LINE
power supply+-15 V
Maximum slew rate13 mA
Supply voltage upper limit22 V
Nominal supply voltage (Vsup)15 V
surface mountNO
technologyBIPOLAR
Temperature levelMILITARY
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationDUAL
Minimum voltage gain20000
Base Number Matches1
