SMS05T1 Series
SC-74 Quad Transient
Voltage Suppressor
for ESD Protection
This quad monolithic silicon voltage suppressor is designed for
applications requiring transient overvoltage protection capability. It is
intended for use in voltage and ESD sensitive equipment such as
computers, printers, business machines, communication systems and
other applications. This quad device provides superior surge
protection over current quad Zener MMQA series by providing up to
350 watts peak power.
Features:
http://onsemi.com
•
SC-74 Package Allows Four Separate Unidirectional Configurations
•
Peak Power – 350 Watts, 8 x 20
mS
•
ESD Rating of Class N (Exceeding 25 kV) per the
Human Body Model
•
ESD Rating:
IEC 61000–4–2 (ESD) 15 kV (air) 8 kV (contact)
IEC 61000–4–4 (EFT) 40 Amps (5/50 ns)
IEC 61000–4–5 (lightning) 23 Amps (8/20
ms)
•
UL Flammability Rating of 94V–0
Typical Applications:
SC–74 QUAD TRANSIENT
VOLTAGE SUPPRESSOR
350 WATTS PEAK POWER
5 VOLTS
3
4
2
PIN ASSIGNMENT
1
5
6
1
2
3
PIN 1.
2.
3.
4.
5.
6.
6
5
4
CATHODE
ANODE
CATHODE
CATHODE
ANODE
CATHODE
SC–74
CASE 318F
STYLE 1
•
Hand Held Portable Applications such as Cell Phones, Pagers,
Notebooks and Notebook Computers
MAXIMUM RATINGS
Rating
Peak Power Dissipation
8 x 20
mS
@ T
A
= 25°C (Note 1)
Total Power Dissipation on FR–5 Board
@ T
A
= 25°C (Note 2)
Derate Above 25°C
Thermal Resistance,
Junction–to–Ambient
Junction and Storage
Temperature Range
Lead Solder Temperature –
Maximum 10 Seconds Duration
Symbol
P
pk
P
D
Value
350
225
1.8
R
qJA
T
J
, T
stg
T
L
556
–55 to
+150
260
Unit
W
mW
mW/°C
°C/W
°C
°C
xxx
d
MARKING
DIAGRAM
xxx
d
= Device Code
= Date Code
ORDERING INFORMATION
Device
SMS05T1
SMS05T3
SMS12T1
SMS12T3
SMS15T1
SMS15T3
SMS24T1
SMS24T3
Package
SC–74
SC–74
SC–74
SC–74
SC–74
SC–74
SC–74
SC–74
Shipping
3000/Tape & Reel
10,000/Tape & Reel
3000/Tape & Reel
10,000/Tape & Reel
3000/Tape & Reel
10,000/Tape & Reel
3000/Tape & Reel
10,000/Tape & Reel
1. Non–repetitive current pulse 8 x 20
mS
exponential decay waveform
2. FR–5 = 1.0 x 0.75 x 0.62 in.
DEVICE MARKING INFORMATION
See specific marking information in the device marking
column of the Electrical Characteristics table on page 2 of
this data sheet.
©
Semiconductor Components Industries, LLC, 2001
1
June, 2001 – Rev. 4
Publication Order Number:
SMS05T1/D
SMS05T1 Series
ELECTRICAL CHARACTERISTICS
(T
A
= 25°C unless otherwise noted)
Symbol
I
PP
V
C
V
RWM
I
R
V
BR
I
T
QV
BR
I
F
V
F
Z
ZT
I
ZK
Z
ZK
Parameter
Maximum Reverse Peak Pulse Current
Clamping Voltage @ I
PP
Working Peak Reverse Voltage
Maximum Reverse Leakage Current @ V
RWM
Breakdown Voltage @ I
T
Test Current
Maximum Temperature Coefficient of V
BR
Forward Current
Forward Voltage @ I
F
Maximum Zener Impedance @ I
ZT
Reverse Current
Maximum Zener Impedance @ I
ZK
I
PP
V
C
V
BR
V
RWM
I
R
V
F
I
T
V
I
F
I
Uni–Directional
ELECTRICAL CHARACTERISTICS – UNIDIRECTIONAL
Max
Reverse
Leakage
Current
I
T
Max
7.2
15
18.5
32
(mA)
1.0
1.0
1.0
1.0
I
R
(mA)
20
1.0
1.0
1.0
V
R
(V)
5.0
12
15
24
Max Reverse Voltage
(Clamping Voltage)
At Specified Reverse
Surge Current (I
RSM
)
I
RSM
(8x20
ms)
(A)
5.0
5.0
5.0
5.0
V
RSM
(8x20
ms)
(V)
9.8
19.0
24.0
40.0
Max Reverse Voltage
(Clamping Voltage)
At Specified Reverse
Surge Current (I
RSM
)
I
RSM
(8x20
ms)
(A)
23
15
12
8
V
RSM
(8x20
ms)
(V)
15.5
23.0
29.0
44.0
Min
250
80
60
40
Capacitance
@ 0 Volt Bias,
1 MHz
(pF)
Max
400
150
125
75
Breakdown
Voltage
V
BR
(V)
Min
6.0
13.3
16.7
26.7
Nom
–
–
–
–
Device
SMS05T1
SMS12T1
SMS15T1
SMS24T1
Device
Marking
5V0
12V
15V
24V
http://onsemi.com
2
SMS05T1 Series
Transient Voltage Suppressors – Surface Mount
350 Watts Peak Power
SC–74 (SC–59ML)
CASE 318F–03
ISSUE F
A
L
6
5
1
2
4
3
NOTES:
1. DIMENSIONING AND TOLERANCING PER ANSI
Y14.5M, 1982.
2. CONTROLLING DIMENSION: INCH.
3. MAXIMUM LEAD THICKNESS INCLUDES LEAD
FINISH THICKNESS. MINIMUM LEAD THICKNESS
IS THE MINIMUM THICKNESS OF BASE
MATERIAL.
4. 318F-01 AND -02 OBSOLETE. NEW STANDARD
318F-03.
DIM
A
B
C
D
G
H
J
K
L
M
S
INCHES
MIN
MAX
0.1142 0.1220
0.0512 0.0669
0.0354 0.0433
0.0098 0.0197
0.0335 0.0413
0.0005 0.0040
0.0040 0.0102
0.0079 0.0236
0.0493 0.0649
0
_
10
_
0.0985 0.1181
CATHODE
ANODE
CATHODE
CATHODE
ANODE
CATHODE
MILLIMETERS
MIN
MAX
2.90
3.10
1.30
1.70
0.90
1.10
0.25
0.50
0.85
1.05
0.013
0.100
0.10
0.26
0.20
0.60
1.25
1.65
0
_
10
_
2.50
3.00
S
B
D
G
M
0.05 (0.002)
H
C
K
J
STYLE 1:
PIN 1.
2.
3.
4.
5.
6.
