821-IF70.0M-GB: DescriptionSAW Filter, 1 Function(s), 70.05MHz, ROHS COMPLIANT PACKAGE-10; CategoryAnalog mixed-signal IC filter; File Size228KB，3 Pages; ManufacturerOscilent; Websitehttp://www.oscilent.com

Download Datasheet View All

821-IF70.0M-GB Overview

SAW Filter, 1 Function(s), 70.05MHz, ROHS COMPLIANT PACKAGE-10

Preview

Download Datasheet

View All

Oscilent Corporation IF SAW Filter | 821-IF70.0M-GB

Page 1 of 3

IF SAW Filter

Part Number

Package

Application

Last Modified

821-IF70.0M-GB

TYPE :

20.0 x 9.8mm SMD

IF SAW Filter

May. 12, 2007

70MHz SAW Filter

PART NUMBER :

821-IF70.0M-GB

OPERATING CONDITIONS / ELECTRICAL CHARACTERISTICS

PARAMETERS

Center Frequency (Fo)

Insertion Loss at Fo

Source Impedance (single ended)*

Load Impedance (single ended)*

Bandwidth -1.0 dB

Bandwidth -3.0 dB

Bandwidth -40.0 dB

Lower Sidelobe

Upper Sidelobe

Amplitude Ripple (Fo +/-9.75MHz)

Attenuation Rejection

Group Delay Variation(Fo +/-9.75MHz)

Absolute Delay @ Fo

Operating Temperature Range

Storage Temperature Range

Maximum DC Voltage

Maximum Input Power

Temperature Coefficient

Minimum

69.95

20.3

-30

-40

Typical

70.0

22.5

20.10

20.40

21.70

0.6

2.35

-72

Maximum

70.15

24.0

21.80

1.0

100

Units

MHz

ohm

MHz

dBp-p

nsec

µsec

°C

dBm

ppm/°C

*With Matching Network(ref. Testing Enviornment Circut as shown below).

Those impedances could be modified with different impedance values and/or structures, if necessary.

PACKAGE OUTLINE

(mm)
