Enclosed Switch
Subminiature Enclosed Switch
H
Coil-spring switch housed in rigid zinc
diecast alloy boasts long life and high
precision
SHL
H
Requires nearly the same operating
force as a conventional precision switch
(0.53 to 0.88 lbf)
H
Molded terminal model is available
H
UL, CSA and/or EN (IEC) approvals
H
Operation-indicator models are
available
Ordering Information
J
LIMIT SWITCHES
Actuator type
yp
Plunger
Panel mount plunger
Panel mount roller plunger
Panel mount cross roller plunger
Short hinge lever
Hinge lever
Short hinge roller lever
Hinge roller lever
One-way action short hinge roller lever
One-way action hinge roller lever
Part number
Standard model
SHL-D55
SHL-Q55
SHL-Q2255
SHL-Q2155
SHL-W55
SHL-W155
SHL-W255
SHL-W2155
SHL-W355
SHL-W3155
Micro voltage/current load model
SHL-D55-01
SHL-Q55-01
SHL-Q2255-01
SHL-Q2155-01
SHL-W55-01
SHL-W155-01
SHL-W255-01
SHL-W2155-01
SHL-W355-01
SHL-W3155-01
Note: For customized models, refer to Molded Terminal Models or Operation-Indicator Equipped Models at the end of this data sheet.
2
SHL
SHL
Specifications
J
RATINGS
General Ratings
Rated voltage
Non-inductive load
Resistive load
NC
125 VAC
250 VAC
480 VAC
8 VDC
14 VDC
30 VDC
125 VDC
250 VDC
Note:
10 A
10 A
2A
10 A
10 A
5A
0.4 A
0.2 A
NO
Lamp load
(See Note 2.)
NC
1.5 A
1.5 A
---
2A
2A
1.5 A
0.4 A
0.2 A
NO
Inductive load
Inductive load
(See Note 1.)
NC
3A
2A
---
5A
5A
1.5 A
0.05 A
0.03 A
NO
Motor load
(See Note 3.)
NC
2.5 A
1.5 A
---
2A
2A
1.5 A
0.05 A
0.03 A
NO
15 A
Inrush current
Inductive loads have a power factor of 0.4 min. (AC) and a time constant of 7 ms max. (DC).
Lamp load has an inrush current of 10 times the steady-state current.
Motor load has an inrush current of 6 times the steady-state current.
UL/CSA Approved Rating
A300
TÜV Rheinland Approved Ratings (EN60947-5-1)
Model
SHL-j55
SHL-j5501
SHL-j55L
SHL-j5501L
SHL-j55L2
SHL-j5501L2
SHL-j55L3
SHL-j5501L3
SHL-j55L4
SHL-j5501L4
SHL-j55L5
SHL-j5501L5
Category and rating
AC-15
DC-12
AC-14
DC-12
AC-15
AC-14
DC-12
DC-12
DC-12
DC-12
DC-12
DC-12
DC-12
DC-12
2 A/125 V
2 A/48 V
0.1 A/125 V
0.1 A/48 V
2 A/125 V
0.1 A/125 V
2 A/12 V
0.1 A/12 V
2 A/24 V
0.1 A/24 V
2 A/24 V
0.1 A/24 V
2 A/48 V
0.1 A/48 V
I
the
5A
4A
0.5 A
0.5 A
5A
0.5 A
4A
0.5 A
4A
0.5 A
4A
0.5 A
4A
0.5 A
3
SHL
Micro Voltage/Current Load Model
Rated voltage
g
Non-inductive load
Resistive load
NC
125 VAC
8 VDC
30 VDC
0.1 A
0.1 A
0.1 A
NO
SHL
Note: This type is ideal for use in the load range
(Zones 1 through 3) shown below.
Voltage (VDC)
SHL-j-01
Zone 2
Zone 4
Zone 0
Zone 1
0.1 W
5 mW
0.2 W
0.5 W
Zone 3
Current (mA)
J
CHARACTERISTICS
Operating speed
Operating frequency
p
g q
y
Insulation resistance
Rated insulation voltage (U
i
)
Rated impulse withstand voltage (U
imp
)
Switching overvoltage
Short-circuit protective device
Conditional short-circuit current
Contact resistance
Dielectric strength
Mechanical
Electrical
0.1 mm to 50 cm m/s for SHL-Q2255 (0.0039 to 19.68 in/s)
120 operations/min
30 operations/min
100 MΩ min. (at 500 VDC)
150 V (IEC947-5-1)
2.5 kV (IEC947-5-1)
1,000 VAC, 300 VDC max. (IEC947-5-1)
10 A fuse (type gG) (IEC269)
100 A (IEC947-5-1)
15 mΩ (initial)
1,000 VAC, 50/60 Hz for 1 min between non-continuous terminals
1,500 VAC, 50/60 Hz for 1 min between each terminal and non-current-carrying
metal part
Malfunction
Destruction
Malfunction
Ambient temperature
(See Note.)
Ambient humidity
Life expectancy
p
y
Enclosure ratings
Clearance and creepage
Weight
Operating
Operating
Mechanical
Electrical
IEC
10 to 55 Hz, 1.5-mm double amplitude
1,000 m/s
2
(approx. 100G) 3.281 ft/sec
2
300 m/s
2
(approx. 30G) 984 ft/sec
2
-
-10°C to 80°C (14°F to 176°F)
95% max.
Pollution degree 3 (IEC947-5-1)
10,000,000 operations min. (at rated OT value)
See
Engineering Data.
IP67
Double insulation
Approx. 62 to 72 g (2.19 to 2.54 oz)
Vibration resistance
Shock resistance
Operating environment pollution level
Note: Temperature range below 0°C are based on absence freezing moisture or water.
4
SHL
J
OPERATING CHARACTERISTICS
Model
OF max.
RF min.
PT max.
OT min.
MD max.
OP
FP max.
Model
OF max.
RF min.
PT max.
OT min.
MD max.
OP
FP max.
SHL-D55
SHL-D55-01
9.81 N (1,000 gf)
2.21 lbf
1.96 N (200 gf)
0.44 lbf
1.5 mm
2 mm
0.5 mm
34±0.8 mm
---
SHL-W155
SHL-W155-01
2.35 N (240 gf)
0.53 lbf
0.44 N (45 gf)
0.10 lbf
13 mm
5 mm
4 mm
21.5±1 mm
34.5 mm
SHL-Q55
SHL-Q55-01
9.81 N (1,000 gf)
2.21 lbf
1.96 N (200 gf)
0.44 lbf
1.5 mm
2 mm
0.5 mm
34±0.8 mm
---
SHL-W255
SHL-W255-01
3.92 N (400 gf)
0.88 lbf
0.78 N (80 gf)
0.18 lbf
8 mm
3 mm
2.5 mm
33±1 mm
41 mm
SHL-Q2255
SHL-Q2255-01
9.81 N (1,000 gf)
2.21 lbf
1.96 N (200 gf)
0.44 lbf
1.5 mm
2 mm
0.5 mm
43±0.8 mm
---
SHL-W2155
SHL-W2155-01
2.55 N (260 gf)
0.57 lbf
0.49 N (50 gf)
0.11 lbf
13 mm
5.5 mm
4 mm
33.5±1 mm
46.5 mm
SHL-Q2155
SHL-Q2155-01
9.81 N (1,000 gf)
2.21 lbf
1.96 N (200 gf)
0.44 lbf
1.5 mm
2 mm
0.5 mm
43±0.8 mm
---
SHL-W355
SHL-W355-01
3.92 N (400 gf)
0.88 lbf
0.75 N (80 gf)
0.17 lbf
8 mm
3 mm
2.5 mm
44.5±1 mm
52.5 mm
SHL-W55
SHL-W55-01
3.14 N (320 gf)
2.21 lbf
0.78 N (80 gf)
0.44 lbf
8 mm
3 mm
2.5 mm
21.5±1 mm
29.5 mm
SHL-W3155
SHL-W3155-01
2.55 N (260 gf)
0.57 lbf
0.49 N (50 gf)
0.11 lbf
13 mm
5.5 mm
4 mm
44.5±1 mm
57.5 mm
SHL
Engineering Data
J
ELECTRICAL LIFE EXPECTANCY
Life expectancy (x 10
6
operations)
10
7
5
3
1
0.7
0.5
0.3
0.1
Operating frequency:
30 operations/min.
(conφ = 1)
250 VAC
Switching current (mA)
5
SHL
SHL
Operation
J
CONTACT FORM
NC
COM
NO
Dimensions
Unit: mm (inch)
J
LIMIT SWITCHES
SHL-D55, SHL-D55-01
7.8 dia. (See Note.)
42.5
10
(0.39)
19
(0.75)
17.5
(0.69)
OP
16
(0.63)
10
(0.39)
13
45.6 (1.80)
54.6 (2.15)
73.5 (2.89)
Two, 4.2 dia.
holes
PT
17.5
M14 x 1
3.5
15 x 15
Terminal
protective
cover
Rubber seal
Note: Stainless steel pin plunger
SHL-Q55, SHL-Q55-01
10
(0.39)
19
(0.75)
17.5
(0.69)
7.8 dia. (See Note.)
PT
M14 x 1
Two hexagon nut
(thickness: 2.5,
width: 16)
16
(0.63)
10
(0.39)
OP
3.5
16.5±02
(0.65±0.0079)
13
15 x 15
Note: Stainless steel pin plunger
SHL-Q2255, SHL-Q2255-01
11 dia.
×
4.7 (See Note.)
PT
M14 x 1
10
(0.39)
19
(0.75)
17.5
(0.69)
Two hexagon nut
(thickness: 2.5,
width: 16)
16
(0.63)
10
(0.39)
13
16.5±02
(0.65±0.0079)
OP
3.5
15 x 15
Note: Sintered stainless alloy roller
Note: Unless otherwise specified, a tolerance of
±0.4
mm applies to all dimensions.
6
